G720-Install-IG101 Installation Guide
CAUTION
The device must be turned off and disconnected from the fabric during this procedure.
NOTE
The illustrations in the rack installation procedures show a 1U device, but the instructions are the same for a 2U
device. The illustrations in the rack installation procedures are for reference only and may not show the actual
device.
Complete the following tasks to install the device in a four-post rack:
1.
Attaching the Front Brackets to the Rear of the Device
2.
Attaching the Extensions to the Front of the Device
3.
Installing the Device in the Rack
4.
Attaching the Rear Brackets to the Extensions at the Front of the Device
5.
Attaching the Rear Brackets to the Front Rack Posts
Attaching the Front Brackets to the Rear of the Device
NOTE
In this installation, the brackets are named as listed in the parts list even though the installation of the brackets is
reversed from the flush-front installation.
Broadcom
®
Brocade
G720 Switch Hardware Installation Guide
G720-Install-IG101
28
