  • Page 1 ® Brocade G710 Switch Hardware Installation Guide Installation Guide October 15, 2024 G710-Install-IG100 October 15, 2024...
  • Page 2 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Table of Contents Introduction............................5 Supported Hardware and Software..........................5 Notes, Cautions, and Danger Notices........................... 5 ® Contacting Technical Support for Your Brocade Product..................5 Document Feedback................................ 6 Device Overview...........................7 License Options................................8 Port-Side View of the Device............................
  • Page 3 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Attaching the Rear Brackets to the Device......................29 Installing the Slide Rack Mount Kit (XBR-R000070)....................29 Time and Items Required............................30 Parts List................................... 30 Preparing the Slide Assemblies..........................32 Attaching the Inner Slide Rails to the Device......................32 Attaching the Rack Mount Brackets.........................
  • Page 4 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide System Status LED..............................59 Management Port LEDs............................59 FC Port (SFP+) Status LEDs........................... 60 Interpreting POST Results............................60 Interpreting Boot Results.............................. 61 Running Diagnostic Tests............................. 61 Technical Specifications........................62 Regulatory Statements........................66 BSMI Statement (Taiwan)...............................66 Canadian Requirements..............................
  • Page 5 OEM and solution providers are trained and certified by Broadcom to support Brocade products. • Broadcom provides backline support for issues that cannot be resolved by the OEM or solution provider. • Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade expertise.
  • Page 6 Brocade G710 Switch Hardware Installation Guide If you purchased Brocade product support directly from Broadcom, use one of the following methods to contact the Technical Assistance Center 24x7. For product support information and the latest information on contacting the Technical Assistance Center, go to www.broadcom.com/support/fibre-channel-networking/contact-brocade-support.
  • Page 7 G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Device Overview The Brocade G710 Switch offers several features and capabilities. NOTE The Brocade G710 Switch is secure-booted. • Up to 24 autosensing ports supporting 64G and 32G small form-factor pluggable plus (SFP+) transceiver port technology in a single domain.
  • Page 8 Real-time clock (RTC) with battery. License Options The Brocade G710 Switch uses a capacity-based Dynamic Ports on Demand (DPOD) license method and can be purchased with 8, 16, or 24 licensed ports. The first eight ports (0–7) are enabled by default. To enable the remaining 16 ports, you must purchase and install up to two 8-port POD license keys.
  • Page 9 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Trunk Port Group 2 (SFP+ FC Ports 8-15) Trunk Port Group 3 (SFP+ FC Ports 0-7) Nonport-Side View of the Device The nonport side of the device is used solely for air flow. Figure 2: Nonport-Side View Device Management Options You can use the management functions built into the device to monitor the fabric topology, port status, physical status, and...
  • Page 10 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Preparing for Installation Perform the following preliminary steps to ensure a successful installation: • Note the safety precautions to avoid harm to you or damage to the device. • Ensure that facility requirements are met. •...
  • Page 11 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide CAUTION Static electricity can damage the chassis and other electronic devices. To avoid damage, keep static-sensitive devices in their static-protective packages until you are ready to install them. NOTE Static electricity can damage the chassis and other electronic devices. To avoid damage, keep static-sensitive devices in their static-protective packages until you are ready to install them.
  • Page 12 All fiber-optic interfaces use Class 1 lasers. DANGER Use only optical transceivers that are qualified by Broadcom and that comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.
  • Page 13 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Quick Installation Checklist The following checklists provide a high-level overview of the basic installation process from the planning stage to the point where the device comes online and is ready to be deployed. Completing all the tasks in the suggested order ensures successful installation.
  • Page 14 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Table 5: Installation and Basic System Configuration Task Task Details or Additional Information Completed Mount the device. Choose one of the following mounting options: • Mount the device as a stand-alone unit. See Installing the Device as a Stand-alone Unit.
  • Page 15 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Task Task Details or Additional Information Completed sysshutdown Optional: Power off the device. Enter the command and wait for the device to power down, and then unplug the power cord. See Powering Down the Device for more information.
  • Page 16 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Mounting the Device You can install the device in several ways: • As a stand-alone unit on a flat surface, for example, a table top. No other equipment is required for desktop installation. •...
  • Page 17 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Installing the 1U and 2U Fixed-Mount Rack Kit for Four-Post Racks (XBR-R000162) Use the following instructions to install a fixed-port device in a fixed-mount configuration using the 1U and 2U Fixed-Mount Rack Kit for Four-Post Racks (XBR-R000162).
  • Page 18 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 3: Rack Kit Parts Bracket, Front Right Bracket, Front Left Bracket, Rear Left Bracket, Rear Right Screw, 8-32 x 5/16-in. Panhead Phillips (12) Screw, 6-32 x 1/4-in. Flathead Phillips (8) Screw, 10-32 x 5/8-in.
  • Page 19 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide NOTE • Not all parts may be used with certain installations depending on the device type. • Although this document describes how to install single-height (1U) and double-height (2U) devices, the illustrations show a single-height device as a typical installation.
  • Page 20 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 4: Attaching the Front Brackets Bracket, Front Right Screw, 8-32 x 5/16-in. Panhead Phillips G710-Install-IG100...
  • Page 21 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Installing the Device in the Rack Perform the following steps to install the device in the rack: 1. Position the device in the rack, as shown in the following figure. Provide temporary support under the device as you secure it to the rack.
  • Page 22 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide NOTE • The preceding figure shows a recessed mounting configuration on the left and a flush mounting configuration on the right. You can select either mounting option. • Install the device with the airflow aligned with any other devices in the rack. Some devices have airflow running from the port side to the fan side, and others have the opposite arrangement.
  • Page 23 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Attaching the Rear Brackets to the Rack Posts Perform the following steps to attach the rear brackets to the rack posts: 1. Attach the right rear bracket to the right rear rack post using two 10-32 x 5/8-in. screws and two retainer nuts, as shown in the following figure.
  • Page 24 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide • Two people are required to install the device in a rack. One person holds the device, while the other person secures the device to the rack. • Before mounting your device, review any specific installation and facility requirements in this hardware installation guide.
  • Page 25 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 8: Rack Kit Parts Bracket, Front Right and Back Left Bracket, Front Left and Back Right Screw, 8-32 x 5/16-in. Panhead Phillips (12) Screw, 6-32 x 1/4-in. Flathead Phillips (8) Screw, 10-32 x 5/8-in.
  • Page 26 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Perform the following steps to attach the front brackets to the device: 1. Position the right front bracket with the flat side against the right side of the device as shown in the following figure. 2.
  • Page 27 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Attaching the Device to a Rack Perform the following steps to install the device in the rack: 1. Position the device in the rack as shown in the following figure, providing temporary support under the device until the rail kit is secured to the rack.
  • Page 28 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Perform the following steps to attach the rear brackets to the rack: 1. Position the right rear bracket in the right rear of the device as shown in the following figure. 2.
  • Page 29 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Attaching the Rear Brackets to the Device Perform the following steps to attach the rear brackets to the device: 1. Align the right rear bracket to the right rear of the device and use two 8-32 x 5/16-in. screws to attach the bracket to the device as shown in the following figure.
  • Page 30 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Time and Items Required Allow 15 to 30 minutes to complete this procedure. The following tools are required to install a device using the Slide Rack Mount Kit: • No. 2 Phillips torque screwdriver •...
  • Page 31 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 14: Rack Kit Parts (2 of 4) Phillips Screw, 10-32 x 1/2 in., Black (12) Three-Hole Rack Nut Bar, 8-32 (4) Alignment Washer (12) Retainer Nut, 10-32 (12) Figure 15: Rack Kit Parts (3 of 4) Left Rack Mount Bracket (unexpected movement safety bracket for port side) (1) Right Rack Mount Bracket (unexpected movement safety bracket for port side) (1) Alternate Left Mount Bracket (unexpected movement safety bracket for port side) (1)
  • Page 32 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Slotted Screw, 8-32 x 3/8 in., Zinc (4) Preparing the Slide Assemblies Perform the following steps to prepare both slide assemblies for installation. 1. Locate the slide assembly in the kit, as shown in the following figure. The slide assembly comes fully assembled and includes all of the parts shown in the following figure.
  • Page 33 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide 3. Attach the rail using three Phillips 8-32 x 3/16-in. screws. 4. Tighten the screws to a torque of 15 in.-lbs (17 cm-kgs). 5. Repeat these steps for the inner slide rail on the other side of the device. Figure 18: Installing the Inner Rail to Allow a Device to Slide out of the Port Side Phillips Screw, 8-32 x 3/16 in., Zinc NOTE...
  • Page 34 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide 3. Tighten the screws to a torque of 15 in.-lbs (17 cm-kgs). 4. Repeat these steps for the left rack mount bracket. Figure 19: Attaching a Rack Mount Bracket Right Rack Mount Bracket (use left rack mount bracket on opposite side) Slotted Screw, 8-32 x 3/8 in., Zinc Attaching the L-Brackets to the Rack Posts Each slide assembly includes two L brackets that attach to the rack posts (either round-hole or square-hole).
  • Page 35 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 20: Repositioning the L Brackets Three-Hole Slide-Mount L Bracket Locking Hex Nut, 8-32 Outer Slide Rail 5/8-in. Reposition Attaching the Rail to Round-Hole Rack Posts Perform the following steps to install the round-hole hardware. 1.
  • Page 36 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide 4. Tighten the screws to 15 in.-lbs (17 cm-kgs). 5. Repeat these steps for the other rail. Figure 21: Attaching Outer Slide Rails to Round-Hole Rack Posts Phillips Screw, 10-32 x 1/2-in., Black (five each side) Three-Hole Slide-Mount L-Bracket (two each side) Rack Post (port side) Outer Slide Rail...
  • Page 37 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Attaching the Rail to Square-Hole Rack Posts (Method A) Perform the following steps to install the square-hole hardware using method A. 1. Position the outer slide rail inside the rack posts with the closed ends of the slide rail toward the nonport side of the rack, as shown in the following figure.
  • Page 38 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide 4. Tighten the screws to 15 in.-lbs (17 cm-kgs). 5. Repeat these steps for the other rail. Figure 22: Method A for Attaching Outer Slide Rails to Square-Hole Rack Posts Phillips Screw, 10-32 x 1/2-in., Black (five each side) Three-Hole Slide-Mount L Bracket (two each side) Rack Post (port side)
  • Page 39 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Attaching the Rail to Square-Hole Rack Posts (Method B) Perform the following steps to install the square-hole hardware using method B. 1. Position the outer slide rail inside the rack posts with the closed ends of the slide rail toward the nonport side of the rack, as shown in the following figure.
  • Page 40 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Outer Slide Rail Three-Hole Slide-Mount L Bracket Alignment Washer (six each side) Rack Post (nonport side) Three-Hole Rack Nut Bar, 8-32 (two each side) Inserting the Device in the Rack Perform the following steps to install the device in the rack.
  • Page 41 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide 2. Insert the power cords into the power cord clips, with the power cord prongs pointing toward the power source. NOTE • Allow a minimum service loop of six in. at the device to ensure freedom to plug and unplug the power cords.
  • Page 42 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 26: Inserting the Device Device Slide Assembly Closed End Outer Slide Rail Slide Assembly Open End Inner Slide Rail Lock-Release Lever 5. Secure the rack mount brackets to the rack posts using one Phillips 10-32 x 1/2-in. screw per bracket and tighten the screws to a torque of 25 in.-lbs (29 cm-kgs).
  • Page 43 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 27: Securing Rack Mount Brackets for Round-Hole Rack Posts Right Rack Mount Bracket Rack Post Three-Hole Rack Nut Bar, 8-32 Phillips Screw, 10-32 x 1/2-in., Black G710-Install-IG100...
  • Page 44 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 28: Method A for Securing Rack Mount Brackets for Square-Hole Rack Posts Right Rack Mount Bracket Rack Post Three-Hole Slide-Mount L Bracket Retainer Nut, 10-32 Phillips Screw, 10-32 x 1/2-in., Black G710-Install-IG100...
  • Page 45 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 29: Method B for Securing Rack Mount Brackets for Square-Hole Rack Post Right Rack Mount Bracket Rack Post Three-Hole Rack Nut Bar, 8-32 Alignment Washer (previously installed) Phillips Screw, 10-32 x 1/2-in., Black G710-Install-IG100...
  • Page 46 Broadcom but are generically branded and can be purchased from other suppliers. Ensure that these USB drives have been formatted using FAT32 before use. For more information on the list of USB drives that have been tested (verified) by Broadcom, refer to the Brocade Fabric OS Software Upgrade Guide.
  • Page 47 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Establishing a First-Time Serial Connection Perform the following steps to log on to the device through a serial connection: 1. Connect the device with the workstation. 2. Disable any serial communication programs running on the workstation, such as any synchronization programs. 3.
  • Page 48 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Configuring the IP Address You can configure the device with a static IP address, or you can use a Dynamic Host Configuration Protocol (DHCP) server to set the IP address of the switch. DHCP is enabled by default. The device supports both IPv4 and IPv6 addresses.
  • Page 49 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide • mm: Specifies the month. Valid values are 01 through 12. • dd: Specifies the date. Valid values are 01 through 31. • hh: Specifies the hour. Valid values are 00 through 23. •...
  • Page 50 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Synchronizing the Local Time with an External Source Perform the following steps to synchronize the local time of the principal or primary FCS device with the time of an external NTP server: 1.
  • Page 51 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Setting the Domain ID Perform the following steps to set the switch domain ID: 1. Log on to the switch through Telnet using the admin account. 2. Modify the domain ID if necessary. The default domain ID is 1.
  • Page 52 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide switchId: fffc19 switchWwn: 10:00:10:ba:b0:1d:a1:20 zoning: OFF switchBeacon: OFF FC Router: OFF HIF Mode: OFF Index Port Address Media Speed State Proto ================================================== 190000 No_Light 190100 No_Light 190200 No_Light 190300 No_Light 190400 No_Light 190500...
  • Page 53 All fiber-optic interfaces use Class 1 lasers. DANGER Use only optical transceivers that are qualified by Broadcom and that comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.
  • Page 54 Brocade Transceiver Support Matrix and the Brocade Transceiver Modules webpage on www.broadcom.com. If you use an unqualified transceiver, the switchshow command output shows the port in a Mod_Inv state. The issue is also logged in the system error log.
  • Page 55 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide 2. Position a cable so that the key (the ridge on one side of the cable connector) is aligned with the slot in the transceiver. Insert the cable into the transceiver until the latching mechanism clicks. Figure 31: Installing SFP+ Cables Cable and Connector Transceiver...
  • Page 56 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Figure 32: Installing SFP+ Transceivers Pull Tab of Transceiver in Upper Row Pull Tab of Transceiver in Lower Row 4. Position a cable so that the key (the ridge on one side of the cable connector) is aligned with the slot in the transceiver. Insert the cable into the transceiver until the latching mechanism clicks.
  • Page 57 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Verifying the Operation of New Transceivers You can use the following commands to verify if the transceivers are working correctly. Refer to the Brocade Fabric OS Command Reference Manual for output examples and descriptions: •...
  • Page 58 Sometimes, the LEDs may flash any of the colors during boot, POST, or other diagnostic tests. This flashing is normal; it indicates a problem only if the LEDs indicate an unhealthy state after all boot processes and diagnostic tests are complete. Figure 34: Brocade G710 Port-Side LEDs System Status LED System Power LED...
  • Page 59 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Table 7: System Power LED Patterns during Normal Operation LED Color Hardware Status Recommended Action No light The system is off, or there is an internal Verify that the system is powered on, that power supply failure.
  • Page 60 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Table 9: Management Port LED Patterns during Normal Operation LED Function/State LED Color Hardware Status Link/Speed Green LED is on. 1000Mb/s link Link/Speed LED is off. Link has no activity. Link is down.
  • Page 61 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide The POST performs the following tasks: • Conducts preliminary diagnostics • Initializes the operating system • Initializes the hardware • Runs diagnostic tests on several functions, including the circuitry, port functionality, memory, statistics counters, and serialization Perform the following steps to determine whether the POST completed successfully and whether any errors were detected:...
  • Page 62 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Technical Specifications The following tables highlight the features and specifications for the Brocade G710 Switch. System Specifications System Component Description Enclosure 1U, nonport-side intake airflow, port-side power inlet. Power inlet C14;...
  • Page 63 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide LEDs System Component Description System power LED One green system power status LED (upper) on the left side. System status LED One bicolor (green/amber) system status LED (lower) on the left side. Ethernet port link LED One link LED on the left of the RJ-45 connector.
  • Page 64 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Data Port Specifications (Fibre Channel) Port Numbers Media Type Description 0 to 23 8G, 16G, 32G, or 64G SFP+ optical ports Switch mode (default): 8-, 16-, and 24-port configurations (8-port increments through Ports on Demand [PoD] licenses);...
  • Page 65 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Signal Description Not supported — Serial Port Specifications (Protocol) Parameter Value Baud 9600 Data bits Parity None Flow control None (must be disabled at the host) Stop bits G710-Install-IG100...
  • Page 66 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Regulatory Statements This section contains regulatory compliance statements for your device. BSMI Statement (Taiwan) Canadian Requirements This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations, ICES-003 Class A.
  • Page 67 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide China ROHS This table is prepared in accordance with the provisions of SJ/T 11364 #: indicates that the content of the toxic and hazardous substance in all the homogeneous materials of the part is below the concentration limit requirement as described in GB/T 26572.
  • Page 68 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide VCCI Statement This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions.
  • Page 69 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Cautions and Danger Notices This section contains translations of safety notices for your product. Cautions A Caution statement alerts you to situations that can be potentially hazardous to you or cause damage to hardware, firmware, software, or data.
  • Page 70 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide PRECAUCIÓN Asegúrese de que el flujo de aire en las inmediaciones de las partes anterior, laterales y posterior del instrumento no esté restringido. Electrical Cautions CAUTION Before plugging a cable into any port, be sure to discharge the voltage stored on the cable by touching the electrical contacts to ground surface.
  • Page 71 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide CAUTION The power supply switch must be in the off position when you insert the power supply into the chassis. Damage to the switch can result if a live power supply is installed. VORSICHT Der Schalter des Netzteils muss in der Stellung „Aus“...
  • Page 72 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide DANGER For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. GEFAHR Aus Sicherheitsgründen sollte ein EGB-Armband zum Schutz von elektronischen gefährdeten Bauelementen mit einem 1 Megaohm-Reihenwiderstand ausgestattet sein. DANGER Pour des raisons de sécurité, la dragonne ESD doit contenir une résistance de série 1 méga ohm.
  • Page 73 Todas las interfaces de fibra óptica utilizan láser de clase 1. DANGER Use only optical transceivers that are qualified by Broadcom and that comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.
  • Page 74 G710 Switch Hardware Installation Guide PELIGRO Utilice sólo transceptores ópticos aprobados por Broadcom y que cumplan con las normas IEC 60825 y EN60825, y con los estándares de rendimiento Clase 1 de FDA definidos en el subcapítulo I de 21 CFR. Los productos ópticos que no cumplan con estos estándares pueden emitir luz dañina para los ojos.
  • Page 75 ® G710-Install-IG100 Installation Guide Brocade G710 Switch Hardware Installation Guide Revision History The revision history provides a list of the significant changes made in each version of the document. G710-Install-IG100; October 15, 2024 Initial document version. G710-Install-IG100...
  • Page 76 Broadcom Support Portal. If you do not have a support account or are unable to log in, please contact your support provider for this information.
