2. Extension Brackets, Medium (2)
3. Rear Brackets, Short (2)
4. Rear Brackets, Long (2)
5. Bracket Extensions, Long (2)
6. Screw, 8-32 x 5/16-in. Panhead Phillips (8)
7. Screw, 8-32 x 5/16-in. Flathead Phillips (16)
8. Screw, 6-32 x 1/4-in. Panhead Phillips (8)
9. Screw, 10-32 x 5/8-in. Panhead Phillips (8)
10. Retainer Nut, 10-32 (8)
Ensure that the items listed and illustrated are included in the kit. Note that not all parts may be used with certain
installations depending on the device type.
CAUTION
Use the screws specified in the procedure. Using longer screws can damage the device.

Flush-Front Mounting

CAUTION
The device must be turned off and disconnected from the fabric during this procedure.
NOTE
The illustrations in the rack installation procedures are for reference only and may not show the device that you
are installing.
Complete the following tasks to install the device in a four-post rack.
1. Attaching the Front Brackets
2. Attaching the Extension Brackets to the Device
3. Installing the Device in the Rack
4. Attaching the Rear Brackets to the Extensions
5. Attaching the Rear Brackets to the Rack Posts
