- Page 1 ® Brocade G720 Switch Hardware Installation Guide Installation Guide 18 December 2020 Broadcom G720-Install-IG101 18 December 2020...
-
Page 2: Table Of Contents
Flush-Front Mounting..............................22 Attaching the Front Brackets..........................23 Attaching the Extension Brackets to the Device....................24 Installing the Device in the Rack........................25 Attaching the Rear Brackets to the Extensions....................26 Attaching the Rear Brackets to the Rack Posts....................27 Broadcom G720-Install-IG101... - Page 3 Establishing an Ethernet Connection.......................... 50 Setting the Domain ID..............................50 Verifying Correct Operation............................51 Backing Up the Configuration............................52 Powering Down the Device............................53 Installing Transceivers and Cables....................54 Precautions Specific to Transceivers and Cables......................54 Cleaning the Fiber-Optic Connectors.......................... 54 Managing Cables................................54 Broadcom G720-Install-IG101...
- Page 4 Removing a Power Supply and Fan Assembly......................67 Inserting a New Power Supply and Fan Assembly....................67 Verifying the Operation of the Power Supply and Fan Assemblies................. 69 Brocade G720 Switch Technical Specifications................70 Regulatory Statements........................74 BSMI Statement (Taiwan)...............................74 Canadian Requirements..............................
- Page 5 ® G720-Install-IG101 Installation Guide Brocade G720 Switch Hardware Installation Guide Cautions...................................80 Danger Notices................................82 Revision History..........................85 Broadcom G720-Install-IG101...
-
Page 6: Copyright Statement
2020 Broadcom. All Rights Reserved. Broadcom, the pulse logo, Brocade, the stylized B logo, and Fabric OS are among the trademarks of Broadcom in the United States, the EU, and/or other countries. The term “Broadcom” refers to Broadcom Inc. and/or its subsidiaries. -
Page 7: Introduction
Introduction About This Document This hardware installation guide contains procedures and safety requirements for installing the Brocade G720 Switch into a rack system or as a stand-alone device. Also provided are steps to initially configure the switch for operation, verify and monitor operation, replace switch field-replaceable units (FRUs), and install transceivers and cables. -
Page 8: Notes, Cautions, And Danger Notices
• Other Resources: Licensing Portal (top), SAN Health (top and bottom), Communities (top), Education (top). If you purchased Brocade product support from a Broadcom OEM/solution provider, contact your OEM/solution provider for all your product support needs. • OEM/solution providers are trained and certified by Broadcom to support Brocade products. -
Page 9: Device Overview
Brocade G720 Switch Hardware Installation Guide Device Overview Hardware Features The Brocade G720 Switch offers the following features and capabilities: NOTE The Brocade G720 Switch is secure-booted. • Enterprise class 56-port Gen 7 Fibre Channel switch that offers 56 x 64Gb/s SFP+ ports in a 1U form-factor. -
Page 10: License Options
• Real-time clock (RTC) with battery. License Options The Brocade G720 Switch uses a capacity-based Ports on Demand (POD) license method. Refer to the Brocade Fabric OS Software Licensing Guide for more details. Port-Side View of the Device The following illustration shows the port-side view of the Brocade G720 Fibre Channel switch. - Page 11 17. SFP+ lower Port 62 18. SFP+ (lower) Port 14 Status LED 19. SFP+ (upper) Port 10 Status LED 20. USB Port 21. UART mini-USB Serial Console Port NOTE All the ports are connected to a single ASIC. Broadcom G720-Install-IG101...
-
Page 12: Nonport-Side View Of The Device
G720 Switch Hardware Installation Guide Nonport-Side View of the Device The following illustration shows the nonport-side view of the Brocade G720 FC switch. Figure 2: Nonport-Side View with AC Power Supply and Fan Assembly Units 1. #6-32 for Screw Mounting of the Ground Cable 2. -
Page 13: Preparing For Installation
If you do not install a module or a power supply in a slot, you must keep the slot filler panel in place. If you run the chassis with an uncovered slot, the system will overheat. CAUTION Do not install the device in an environment where the operating ambient temperature might exceed 40°C (104°F). Broadcom G720-Install-IG101... -
Page 14: Esd Precautions
(amp) ratings of all devices installed on the same circuit as the device. Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the devices near the input power connectors. Broadcom G720-Install-IG101... -
Page 15: Lifting And Weight-Related Precautions
All fiber-optic interfaces use Class 1 lasers. DANGER Use only optical transceivers that are qualified by Broadcom and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes. -
Page 16: Quick Installation Checklist
See Mounting Options. Review and verify installation Verify that the following requirements are met. See Facility Requirements. • requirements. Power requirements • Environmental requirements • Clearance for stand-alone or rack installation Broadcom G720-Install-IG101... - Page 17 Customizing the Chassis Name and Switch Name for more information. Establish an Ethernet connection. By establishing an Ethernet connection, you can complete the device configuration using a serial session, Telnet, or management application, such as Brocade SANnav Management Portal. See Establishing an Ethernet Connection. Broadcom G720-Install-IG101...
-
Page 18: Shipping Carton Contents
– Rubber feet – RoHS hazardous toxic substance content chart – Download Instructions for Fibre Channel Networking Software and Documents • Inner foam NOTE Transceivers may be shipped in the accessory tray instead of installed in switch ports. Broadcom G720-Install-IG101... -
Page 19: Mounting The Device
CAUTION To prevent damage to the chassis and components, never attempt to lift the chassis using the fan or power supply handles. These handles were not designed to support the weight of the chassis. Broadcom G720-Install-IG101... -
Page 20: Stand-Alone Installation
Before mounting your device, review any specific installation and facility requirements in the hardware installation guide for the device. • Hardware devices illustrated in these procedures are for reference only and may not depict the device that you are installing into the rack. Broadcom G720-Install-IG101... -
Page 21: Time And Items Required
No. 2 Phillips torque screwdriver • 1/4-in. slotted-blade torque screwdriver Parts List The following parts are provided with the 1U, 1.5U, and 2U Universal Four-Post Rack Kit (XBR-R000296): Figure 3: Universal Four-Post Rack Kit Parts 1. Front Brackets (2) Broadcom G720-Install-IG101... -
Page 22: Flush-Front Mounting
Complete the following tasks to install the device in a four-post rack. Attaching the Front Brackets Attaching the Extension Brackets to the Device Installing the Device in the Rack Attaching the Rear Brackets to the Extensions Attaching the Rear Brackets to the Rack Posts Broadcom G720-Install-IG101... -
Page 23: Attaching The Front Brackets
3. Repeat Step 1 and Step 2 to attach the left front bracket to the left side of the device. 4. Tighten all 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 4: Attaching the Front Brackets 1. Brocade Device 2. Front Brackets 3. Screws, 8-32 x 5/16-in. Flathead Phillips Broadcom G720-Install-IG101... -
Page 24: Attaching The Extension Brackets To The Device
4. Repeat Steps 2 and 3 to attach the left extension bracket to the left side of the device. 5. Tighten all 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 5: Attaching the Extension Brackets to the Device 1. Extension Bracket 2. Screws, 8-32 x 5/16-in. Flathead Phillips Broadcom G720-Install-IG101... -
Page 25: Installing The Device In The Rack
Use the upper and lower holes in the bracket. 3. Tighten all 10-32 x 5/8-in. screws to a torque of 29 cm-kg (25 in.-lb). Figure 6: Positioning the Device in the Rack 1. Screws, 10-32 x 5/8-in. Panhead Phillips 2. Retainer Nuts, 10-32 Broadcom G720-Install-IG101... -
Page 26: Attaching The Rear Brackets To The Extensions
5. Adjust the brackets to the rack depth and tighten all 6-32 x 1/4-in. screws to a torque of 10 cm-kg (9 in.-lb). Figure 7: Attaching the Rear Brackets to the Extensions 1. Rear Brackets 2. Screws, 6-32 x 1/4-in. Panhead Phillips Broadcom G720-Install-IG101... -
Page 27: Attaching The Rear Brackets To The Rack Posts
Figure 8: Attaching the Rear Brackets to the Rack Posts 1. Screws, 10-32 x 5/8-in. Panhead Phillips 2. Retainer Nuts, 10-32 Flush-Rear (Recessed) Mounting Flush-rear (recessed) mounting is similar to flush-front mounting except that the brackets are reversed on the device. Broadcom G720-Install-IG101... -
Page 28: Attaching The Front Brackets To The Rear Of The Device
Attaching the Rear Brackets to the Front Rack Posts Attaching the Front Brackets to the Rear of the Device NOTE In this installation, the brackets are named as listed in the parts list even though the installation of the brackets is reversed from the flush-front installation. Broadcom G720-Install-IG101... - Page 29 4. Tighten all 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 9: Attaching the Front Brackets to the Rear of the Device 1. Brocade Device 2. Front Brackets 3. Screws, 8-32 x 5/16-in. Flathead Phillips Broadcom G720-Install-IG101...
-
Page 30: Attaching The Extensions To The Front Of The Device
4. Repeat Steps 2 and 3 to attach the left front extension bracket to the left side of the device. 5. Tighten all the 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 10: Attaching the Extensions to the Device 1. Extensions 2. Screws, 8-32 x 5/16-in. Flathead Phillips Broadcom G720-Install-IG101... -
Page 31: Installing The Device In The Rack
Use the upper and lower holes in the bracket. 3. Tighten all 10-32 x 5/8-in. screws to a torque of 29 cm-kg (25 in.-lb). Figure 11: Positioning the Device in the Rack 1. Screws, 10-32 x 5/8-in. Panhead Phillips 2. Retainer Nuts, 10-32 Broadcom G720-Install-IG101... -
Page 32: Attaching The Rear Brackets To The Extensions At The Front Of The Device
5. Adjust the brackets to the rack depth, and tighten all 6-32 x 1/4-in. screws to a torque of 10 cm-kg (9 in.-lb). Figure 12: Attaching the Rear Brackets to the Extensions at the Front of the Device 1. Rear Brackets, Short 2. Screws, 6-32 x 1/4-in. Panhead Phillips Broadcom G720-Install-IG101... - Page 33 ® G720-Install-IG101 Installation Guide Brocade G720 Switch Hardware Installation Guide Figure 13: Attaching the Short or Long Rear Brackets to the Extensions 1. Rear Bracket, Short or Long 2. Screws, 6-32 x 1/4-in. Panhead Phillips Broadcom G720-Install-IG101...
-
Page 34: Attaching The Rear Brackets To The Front Rack Posts
1. Screws, 10-32 x 5/8-in. Panhead Phillips 2. Retainer Nuts, 10-32 Installing the Universal Two-Post Rack Kit (XBR–R000294) Use the following instructions to install a Brocade 1U or 2U device in a two-post telecommunications (telco) rack using the Universal Two-Post Rack Kit (XBR-R000294). Broadcom G720-Install-IG101... -
Page 35: Time And Items Required
1/4-in. slotted-blade torque screwdriver Parts List The following parts are provided with the Universal Two-Post Rack Kit (XBR-R000294): Figure 15: Universal Two-Post Rack Kit Parts 1. Front Brackets (2) 2. Rear Brackets, 5–6-in. Post (2) 3. Rear Brackets, 3–5-in. Post (2) Broadcom G720-Install-IG101... -
Page 36: Flush-Front Mounting
Complete the following tasks to install the device in the rack: Attaching the Front Brackets to the Device Attaching the Front Brackets to the Rack Attaching the Rear Brackets to the Rack Attaching the Rear Brackets to the Device Broadcom G720-Install-IG101... -
Page 37: Attaching The Front Brackets To The Device
4. Tighten all the 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 16: Attaching the Front Brackets 1. Brocade Device 2. Front Brackets, Right and Left 3. Screws, 8-32 x 5/16-in. Flathead Phillips Broadcom G720-Install-IG101... -
Page 38: Attaching The Front Brackets To The Rack
Use the upper and lower holes in the bracket. 4. Tighten all the 10-32 x 5/8-in. screws to a torque of 29 cm-kg (25 in.-lb). Figure 17: Attaching the Front Brackets to the Rack 1. Screws, 10-32 x 5/8-in. Panhead Phillips 2. Retainer Nuts, 10-32 Broadcom G720-Install-IG101... -
Page 39: Attaching The Rear Brackets To The Rack
5. Tighten all the 10-32 x 5/8-in. screws to a torque of 29 cm-kg (25 in.-lb). Figure 18: Attaching the Rear Brackets to the Rack 1. Retainer Nuts, 10-32 2. Rear Brackets 3. Screws, 10-32 x 5/8-in. Panhead Phillips Broadcom G720-Install-IG101... -
Page 40: Attaching The Rear Brackets To The Device
3. Tighten all the 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 19: Attaching the Rear Brackets to the Device 1. Screws, 8-32 x 5/16-in. Panhead Phillips Mid-Mounting Observe the following notes when performing this procedure: Broadcom G720-Install-IG101... - Page 41 Complete the following tasks to install the device in the rack: Attaching the Front Brackets to the Device Attaching the Front Brackets to the Rack Attaching the Rear Brackets to the Rack Attaching the Rear Brackets to the Device Broadcom G720-Install-IG101...
-
Page 42: Attaching The Front Brackets To The Device
3. Repeat Steps 1 and 2 to attach the left front bracket to the left side of the device. 4. Tighten all 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 20: Attaching the Front Brackets 1. Brocade Device 2. Front Brackets, Right and Left 3. Screws, 8-32 x 5/16-in. Flathead Phillips Broadcom G720-Install-IG101... -
Page 43: Attaching The Front Brackets To The Rack
4. Tighten all 10-32 x 5/8-in. screws to a torque of 29 cm-kg (25 in.-lb). Figure 21: Attaching the Front Brackets to the Rack 1. Screws, 10-32 x 5/8-in. Panhead Phillips 2. Retainer Nuts, 10-32 Broadcom G720-Install-IG101... -
Page 44: Attaching The Rear Brackets To The Rack
5. Tighten all 10-32 x 5/8-in. screws to a torque of 29 cm-kg (25 in.-lb). Figure 22: Attaching the Rear Brackets to the Rack 1. Retainer Nuts, 10-32 2. Rear Brackets (Right and Left) 3. Screws, 10-32 x 5/8-in. Panhead Phillips Broadcom G720-Install-IG101... -
Page 45: Attaching The Rear Brackets To The Device
Again, use the upper and lower slots in the bracket. 3. Tighten all 8-32 x 5/16-in. screws to a torque of 17 cm-kg (15 in.-lb). Figure 23: Attaching the Rear Brackets to the Device 1. Screws, 8-32 x 5/16-in. Panhead Phillips Broadcom G720-Install-IG101... -
Page 46: Initial Setup And Verification
Access to an FTP server or USB device for uploading (backing up) or downloading the device configuration (optional). NOTE Brocade recommends the use of a USB drive that has been test validated (verified) by Broadcom (Brocade): • SanDisk 32 CZ48 USB 3.0 Flash Drive (SDCZ48-032G-UAM46) •... -
Page 47: Establishing A First-Time Serial Connection
Initial passwords can be 8 to 40 characters long. They must begin with an alphabetic character. They can include numeric characters, the period (.), and the underscore (_) only. Passwords are case-sensitive, and they are not displayed when you enter them on the command line. Broadcom G720-Install-IG101... -
Page 48: Configuring The Ip Address
The "new-date" variable specifies the new date and time and is enclosed in double quotation marks. This variable is optional; if omitted, the current date and time are displayed. The date and time are specified as a string in mmddhhmmyy format: Broadcom G720-Install-IG101... -
Page 49: Setting The Time Zone
Atlantic Standard -4,0 Atlantic Daylight -3,0 Eastern Standard -5,0 Eastern Daylight -4,0 Central Standard -6,0 Central Daylight -5,0 Mountain Standard -7,0 Mountain Daylight -6,0 Pacific Standard -8,0 Pacific Daylight -7,0 Alaskan Standard -9,0 Alaskan Daylight -8,0 Hawaiian Standard -10,0 Broadcom G720-Install-IG101... -
Page 50: Synchronizing The Local Time With An External Source
The default domain ID is 1. If the switch is not powered on until after it is connected to the fabric and the default domain ID is already in use, the domain ID for the new switch is automatically reset to a unique value. If the switch is Broadcom G720-Install-IG101... -
Page 51: Verifying Correct Operation
The switchShow command provides the following information about the device and ports status. G720switch:admin> switchshow switchName: E_146156_C5c_LS1 switchType: 181.0 switchState: Online switchMode: Native switchRole: Subordinate switchDomain: switchId: fffc9c switchWwn: 10:00:d8:1f:cc:12:c0:cd zoning: ON (fos6k) switchBeacon: FC Router: Fabric Name: FID1 HIF Mode: Allow XISL Use: ON Broadcom G720-Install-IG101... -
Page 52: Backing Up The Configuration
Server Name or IP Address [host]: 192.0.2.0 User Name [user]: anonymous Path/Filename [(home dir>/config.txt]: home/dumps/config.fid100.txt Section (all|chassis|FID# [all]): configUpload complete: All selected config parameters are uploaded 2020/03/05-23:57:59, [CONF-1001], 130, FID 128, INFO, E_146155_C5c, configUpload completed successfully for all. Broadcom G720-Install-IG101... -
Page 53: Powering Down The Device
3. Power off both power supplies by setting each power switch to the “O” position. 4. Unplug the power cables from the power source before servicing the device or FRUs. All devices are returned to their initial state the next time the switch is powered on. Broadcom G720-Install-IG101... -
Page 54: Installing Transceivers And Cables
All fiber-optic interfaces use Class 1 lasers. DANGER Use only optical transceivers that are qualified by Broadcom and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes. -
Page 55: Replacing An Sfp+ Transceiver
Brocade G720 Switch Hardware Installation Guide Modules webpage on www.broadcom.com. If you use an unqualified transceiver, the switchshow command output shows the port in a Mod_Inv state. The issue is also logged in the system error log. To insert an SFP+ transceiver, complete the following steps: NOTE The 32Gb/s and 64Gb/s SFP+ transceivers do not have bails. - Page 56 SFP+ transceiver into the upper row of ports is with the gold edge down. The correct position to insert an SFP+ transceiver into the lower row of ports is with the gold edge up. Figure 25: Replacing an SFP+ Optical Transceiver in an Upper Port 1. Pull Tab 2. SFP+ Cable 3. SFP+ Transceiver Broadcom G720-Install-IG101...
-
Page 57: Verifying The Operation Of New Transceivers
Verifying the Operation of New Transceivers You can use the following commands to verify if the transceivers are working correctly: • errDump • fabricShow • sfpShow • switchShow Refer to the Brocade Fabric OS Command Reference Manual for output examples and descriptions. Broadcom G720-Install-IG101... -
Page 58: Monitoring The Device
Sometimes, the LEDs may flash either of the colors during boot, POST, or other diagnostic tests. This flashing is normal; it indicates a problem only if the LEDs indicate an unhealthy state after all boot processes and diagnostic tests complete. Figure 26: Brocade G720 Switch Port-Side LEDs - Left Side 1. System Power LED 2. -
Page 59: System Power Led
® G720-Install-IG101 Installation Guide Brocade G720 Switch Hardware Installation Guide Figure 27: Brocade G720 Switch Port-Side LEDs - Right Side 1. SFP+ Upper Port 48 2. SFP+ Upper Port 50 3. SFP+ Lower Port 52 4. SFP+ Lower Port 54 5. -
Page 60: Management Port Leds
FC Port Status LEDs On the Brocade G720 Switch, you find 48 LEDs (green/amber) for the first 48 SFP+ ports and 8 tri-color LEDs (green/ amber/white) for the last 8 SFP+ ports 48, 50, 52, 54, 56, 60, and 62. The tri-color LEDs pulse once in white, before indicating the FC port status in green or amber. -
Page 61: Interpreting Nonport-Side Leds
The power cable is disconnected (flashing for ~ 5 assembly. seconds, then off). • The power supply and fan assembly has failed. When the device is first powered on, the power supply and fan assembly status LED flashes until the POST has completed. Broadcom G720-Install-IG101... -
Page 62: Interpreting Post Results
Diagnostic tests are run at supported link speeds depending on the speed of the link being tested and the type of port. NOTE Diagnostic tests may temporarily lock the transmit and receive speed of the links. NOTE Power-cycle the device after completing offline diagnostics tests. Broadcom G720-Install-IG101... -
Page 63: Power Supply And Fan Assembly
Power Supply and Fan Assembly Overview The Brocade G720 chassis has two 350W power supply and fan assemblies. The power supply and fan assembly units can be removed and replaced without special tools. The device can continue operating during the replacement. -
Page 64: Precautions Specific To The Power Supply And Fan Assemblies
If the ambient temperature is above the recommended operational limits, the power supply units shutdown, which in turn shuts down the device without any warning message. Identifying the Airflow Direction The power supply and fan assemblies are identified by the following airflow directions: Broadcom G720-Install-IG101... -
Page 65: Airflow And Encr Error Monitoring
Installing an Additional Power Supply and Fan Assembly (Hot-Install) If your device is up and running with a single power supply and fan assembly and you want to install an additional power supply, complete the following steps. 1. Remove the existing filler panel. Broadcom G720-Install-IG101... -
Page 66: Time And Items Required
New power supply and fan assembly (must have the same airflow direction as the power supply and fan assembly being replaced) • #1 Phillips-head screwdriver Recording Critical Information about the Power Supply and Fan Assembly You can use the following commands to record the power supply and fan assembly configuration and operation information: Broadcom G720-Install-IG101... -
Page 67: Removing A Power Supply And Fan Assembly
Complete the following steps to insert a new power supply and fan assembly into the chassis. CAUTION The power supply switch must be in the off position when you insert the power supply into the chassis. Damage to the switch can result if a live power supply is installed. Broadcom G720-Install-IG101... - Page 68 If the LED is not a steady green, ensure that the power supply is securely installed and seated properly. 8. Optional: Enter psshow to display the PSU status. The power supply and fan assembly status can also be viewed using Web Tools. Broadcom G720-Install-IG101...
-
Page 69: Verifying The Operation Of The Power Supply And Fan Assemblies
You can use the following commands to verify that the power supply and fan assemblies are operational: • errDump • fanShow • psShow • switchShow Refer to the Brocade Fabric OS Command Reference Manual for output examples and descriptions. Broadcom G720-Install-IG101... -
Page 70: Brocade G720 Switch Technical Specifications
® G720-Install-IG101 Installation Guide Brocade G720 Switch Hardware Installation Guide Brocade G720 Switch Technical Specifications The following tables highlight the features and specifications for the Brocade G720 Switch. System Specifications System Component Description Enclosure 1U, port-side back-to-front exhaust airflow, power from the back. - Page 71 Empty weight refers to the device with two power-supply and fan assemblies installed but no SFP+ or QSFP transceivers. Weight (Fully Model Height Width Depth Weight (Empty) Loaded) Brocade G720 4.39 cm 44.00 cm 35.56 cm 7.05 kg 8.08 kg Switch 1.73 in.
- Page 72 100m (328 ft) (OM3) 125m (410 ft) (OM4) 62.5 15m (49 ft) 10 km (6.2 miles) 70m (230 ft) (OM3) 100m (328 ft) (OM4) 62.5 10 km (6.2 miles) 70m (230 ft) (OM3) 100M (328 ft) (OM4 and OM5) 62.5 Broadcom G720-Install-IG101...
- Page 73 Data Port Specifications (Fibre Channel) Model Name Port Numbers Media Type Description Brocade G720 Ports 0–47, 48, 50, 52, 56 SFP+ optical ports, up to 64Gb/s, Can be an F_Port, N_Port, E_Port, or EX_Port. Switch 54, 56, 58, 60, and 62...
-
Page 74: Regulatory Statements
European Council directives, laws, and standards: • Electromagnetic Compatibility (EMC) Directive 2014/30/EU • Low Voltage Directive (LVD) 2014/35/EU • EN 55032/EN 55024 (European Immunity Requirements) – EN61000-3-2/JEIDA (European and Japanese Harmonics Spec) – EN61000-3-3 Broadcom G720-Install-IG101... -
Page 75: China Ccc Statement
® G720-Install-IG101 Installation Guide Brocade G720 Switch Hardware Installation Guide China CCC Statement Broadcom G720-Install-IG101... -
Page 76: China Rohs
KCC Statement (Republic of Korea) Class A device (Broadcasting Communication Device for Office Use): This device obtained EMC registration for office use (Class A), and may be used in places other than home. Sellers and/or users need to take note of this. Broadcom G720-Install-IG101... -
Page 77: Taiwan Rohs Certification
® G720-Install-IG101 Installation Guide Brocade G720 Switch Hardware Installation Guide Taiwan ROHS Certification Broadcom G720-Install-IG101... -
Page 78: Vcci Statement
FCC Part 15, Subpart B (Class A) • GB 9254 • ICES-003 (Canada) • KN 32 • KN 35 • VCCI-32 (Japan) Regulatory Compliance (Safety) • 2014/35/EU • EN/IEC 60950-1 • EN/UL 60825 • EN/UL/CSA/IEC 62368-1 • GB 4943.1 Broadcom G720-Install-IG101... - Page 79 Section 1502 of the Dodd-Frank Wall Street Reform and Consumer Protection Act of 2010 - U.S. Conflict Minerals. • SJ/T 11363 – 2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364 – 2006 Marking for the Control of Pollution Caused by EIPs (China). Broadcom G720-Install-IG101...
-
Page 80: Cautions And Danger Notices
Vérifiez que rien ne restreint la circulation d'air devant, derrière et sur les côtés du dispositif et qu'elle peut se faire librement. PRECAUCIÓN Asegúrese de que el flujo de aire en las inmediaciones de las partes anterior, laterales y posterior del instrumento no esté restringido. Broadcom G720-Install-IG101... - Page 81 Siga cuidadosamente las guías mecánicas de cada lado de la ranura del suministro de energía y verifique que el suministro de energía está insertado correctamente en las guías. No inserte nunca el suministro de energía de manera invertida. Broadcom G720-Install-IG101...
- Page 82 DANGER Pour des raisons de sécurité, la dragonne ESD doit contenir une résistance de série 1 méga ohm. PELIGRO Por razones de seguridad, la correa de muñeca ESD deberá contener un resistor en serie de 1 mega ohmio. Broadcom G720-Install-IG101...
- Page 83 Les batteries utilisées pour la sauvegarde de l'horloge et de la mémoire ne sont pas remplaçables par l'opérateur. Il y a risque d'explosion si la batterie est remplacée par une d'un type incompatible. Jetez/recyclez les batteries conformément aux normes locales. Broadcom G720-Install-IG101...
- Page 84 Todas las interfaces de fibra óptica utilizan láser de clase 1. DANGER Use only optical transceivers that are qualified by Broadcom and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.
- Page 85 G720 Switch Hardware Installation Guide Revision History G720-Install-IG101; 18 December 2020 • Added support for 64Gb/s optical transceivers. • Added the chapter Brocade G720 Switch Technical Specifications. • Added the section Regulatory Compliance. G720-Install-IG100; 30 April 2020 Initial document version.
