Broadcom Brocade G720 Hardware Installation Manual page 71

G720-Install-IG101 Installation Guide
LEDs
System Component
System power LED
System status LED
Ethernet port speed LED
Ethernet port activity LED
FC port status LEDs
Power supply and fan assembly
status LEDs
Cables, Connectors, and Adapters
System Component
Serial cable
RJ-45 to mini-USB adapter
Mini-USB
Weight and Physical Dimensions
Empty weight refers to the device with two power-supply and fan assemblies installed but no SFP+ or QSFP transceivers.
Model
Brocade G720 4.39 cm
Switch
1.73 in.
Environmental Requirements
Condition
Ambient temperature
Relative humidity
(noncondensing)
Altitude (above sea level) 0m to 3000m (9842 feet)
Shock
Vibration
Airflow
Operating noise
Broadcom
One green system power status LED (upper) on the port side.
One bicolor (green/amber) system status LED (lower) on the port side.
One status LED on the right of the RJ-45 connector. Glows green for 1000Mb/s and off for
100/10Mb/s.
One link activity LED on the left of the RJ-45 connector.
48 LEDs (green/amber) for the first 48 SFP+ ports and 8 tri-color LEDs (green/amber/white) for the
last 8 SFP+ ports 48, 50, 52, 54, 56, 58, 60, and 62. The last set of LEDs pulse once in white, before
indicating the FC port status in green or amber. All functionalities pertaining to the green/amber
colors for the last 8 LEDs remain the same as the first 48 LEDs.
One green power-supply and fan-assembly status LED on each power supply and fan assembly on
the nonport side of the switch.
RJ-45 console cable.
RJ-45 to mini-USB for the console cable.
USB socket for the serial port.
Height Width
44.00 cm
17.32 in.
Operational
0°C to 40°C (32°F to 104°F)
10% to 85% at 40°C (104°F)
20.0G, 6 ms, half-sine wave
0.25G sine, 0.4 grams random, 5–500 Hz
Maximum: 170 cmh (100 cfm)
Nominal: 120 cmh (71 cfm)
Maximum: 65 dB
Description
Description
Depth Weight (Empty)
35.56 cm 7.05 kg
14.00 in. 15.54 lb
–25°C to 70°C (–13°F to 158°F)
10% to 90% noncondensing
0m to 12,000m (39,370 feet)
33.0G, 11 ms, half-sine wave, 3G axis
5 Hz at 0.5 grams, 10–500 Hz at 1.0 grams (sine
vibration); 3–500 Hz at 1.12 grams (random
vibration)
N/A
N/A
®
Brocade G720 Switch Hardware Installation Guide
Weight (Fully
Loaded)
8.08 kg
17.81 lb
Nonoperational
G720-Install-IG101
71
