both obligatory fields. To add the device's location you can
search for it using the option
open an interactive map, or you can manually enter the ad-
dress and coordinates.
Click on 'Save'
Obligatory fields are marked with an asterisk (*).
60
'Search location', which will
to complete the process.
Once the process is complete, a message similar to the one
below will appear and the new device will be added to your list
of registered devices.
11.2.2. General technical specifications
In the Tab. 6 below lists the technical specifications of the
NIMBUS card:
Specifications
Processor Sitara AM3358BZCZ100 1GHz, 2000 MIPS
Graphics card SGX530 3D, 20M Polygons/S
SDRAM memory 512MB DDR3L 800 MHz
Flash memory 4GB, 8bit MMC integrated
PMIC TPS65217C PMIC regulator and an additional LDO.
Debug support Optional Onboard 20-pin CTI JTAG
SD/MMC connector MicroSD, 3.3V
Audio HDMI interface, stereo
Tab. 23. Technical specifications of the NIMBUS card.
