Disconnector
Manual Bypass (Optional)
Fig. 6. Front view (left) and rear view (right) of the 42U
cabinet with 4 modules installed.
USER MANUAL
Communications interface
(See ) + Bypass Module
Battery
Isolator
Switch
Power
modules
External battery
Manual Bypass
Terminals
(Optional)
terminals
Terminal block,
See Detail A,
page 7
SLC ADAPT 2 - UNINTERRUPTIBLE POWER SUPPLY SYSTEM -
11
