7.5. TABLES OF ALARMS, WARNINGS AND EVENTS.
7.5.1. Table of UPS Alarms.
No. NAME OF ALARM
1 ALM_EPO
2 ALM_BYPASS_SEQUENCE_ERROR
3 ALM_BYPASS_SCR_FAIL_OPEN
4 ALM_BYPASS_SCR_FAIL_SHORTED
5 ALM_BYPASS_OVER_LOAD_TOUT
6 ALM_OUTPUT_SHORT_CIRCUIT
7 ALM_BATTERY_EOD
8 ALM_RECTIFIER_FAIL
9 ALM_INVERTER_FAIL
10 ALM_RECTIFIER_OVER_TEMP
11 ALM_FAN_FAIL
12 ALM_OUTPUT_OVER_LOAD
13 ALM_INVERTER_OVERLOAD_TOUT
14 ALM_INVERTER_OVER_TEMP
15 ALM_ON_UPS_INHIBITED
16 ALM_BATTERY_REVERSE
17 ALM_INVERTER_PROTECT
18 ALM_INPUT_NEUTRAL_LOST
19 ALM_BYPASS_FAN_FAIL
20 ALM_PARALLEL_CABLE_ERROR
21 ALM_REC_CAN_FAIL
22 ALM_INV_IO_CAN_FAIL
23 ALM_INV_DATA_CAN_FAIL
24 ALM_SYNC_PULSE_FAIL
25 ALM_BATTERY_VOLT_DETECT_FAIL Low battery
26 ALM_OUTPUT_VOLT_FAIL_R
27 ALM_OUTPUT_VOLT_FAIL_S
28 ALM_OUTPUT_VOLT_FAIL_T
29 ALM_INV_BRIDGE_FAIL
30 ALM_INPUT_CURR_UNBALANCE
31 ALM_REC_SOFT_START_FAIL
32 ALM_RELAY_CONNECT_FAIL
33 ALM_RELAY_SHORT_CIRCUIT
34 ALM_PWM_SYNC_FAIL
35 ALM_INPUT_OVER_CURR_TOUT
36 ALM_NO_INLET_TEMP_SENSOR
37 ALM_NO_OUTLET_TEMP_SENSOR
38 ALM_BYPASS_CAN_FAIL
39 ALM_FIRMWARE_ERROR
40 ALM_SYSTEM_SETTING_ERROR
41 ALM_MODULE_ID_DUPLICATE
42 ALM_INV_IGBT_OVERCURRENT
43 ALM_REDUNDANT_OVL_TOUT
44 ALM_NO_OUTPUT
45 ALM_MAINT_BYPASS
USER MANUAL
DESCRIPTION
Emergency Power Off
Phase sequence failure in Bypass
Semiconductor fault in Bypass, Open-circuit SCR.
Semiconductor fault in Bypass, Short-circuit SCR.
Bypass Overload Timed-out
Short-circuit in Output
The battery has reached End of Backup
Rectifier fault
Inverter fault
Rectifier over-temperature
Fan fault
Overload at Output
Inverter Overload Timed-out
Inverter over-temperature
The UPS is disabled, cannot switch to Inverter
Battery polarity fault
Over-current protection tripped in Inverter
Neutral connection fault
Fan fault in Bypass
Connection fault in parallel communications cable
CAN bus connection fault in Rectifier
CAN bus connection fault in Current Sharing between Modules
CAN bus connection fault in Inverter
Fault in the low-frequency synchronisation signal
Inverter output voltage fault in Phase R
Inverter output voltage fault in Phase S
Inverter output voltage fault in Phase T
Fault in an IGBT half-bridge branch in Inverter
Rectifier input current unbalanced
Rectifier soft-start circuit fault
Fault in Inverter Connection Relay output
Inverter Connection Relay Short-circuit
Fault in the PWM Synchronisation signal
Rectifier Overload Timed-out
No temperature sensor in external air inlet
No temperature sensor in external air outlet
Fault alarm in Bypass CAN bus
A module contains unrecognised firmware
System file corrupt or erroneous. The module configuration does not
correspond to the type of module.
Duplicate Module Address
Over-current in the IGBTs in one of the Modules
Non-redundant Modules Overload Timed-out
Output voltage fault
Maintenance Bypass Switch Connected
TYPE OF ALARM
UPS
UPS
UPS
UPS
UPS
MODULE
UPS
MODULE
MODULE
MODULE
MODULE
MODULE
MODULE
MODULE
UPS
MODULE
MODULE
MODULE
UPS
UPS
UPS
MODULE
UPS
MODULE
UPS
UPS
UPS
UPS
MODULE
MODULE
MODULE
MODULE
MODULE
MODULE
MODULE
MODULE
MODULE
UPS
UPS
MODULE
MODULE
MODULE
UPS
UPS
UPS
