- Page 1 USER'S MANUAL MAKE BEFORE BREAK MANUAL BYPASS PANEL FOR UPS (BM*): SLC ADAPT SLC ADAPT-X SLC ADAPT 2 SLC CUBE 3+ SLC CUBE 4 (7,5-80 kVA) SLC X-PERT SLC X-TRA SLC TWIN PRO2...
- Page 2 SALICRU...
- Page 3 General index 1. INTRODUCTION. 6. START UP AND SHUTDOWN. 1.1. ACKNOWLEDGEMENT LETTER. 6.1. CONTROLS BEFORE THE START UP. 2. INFORMATION FOR SAFETY. 6.2. OPERATION TO SHIFT FROM «OUT OF SERVICE» (UPS OR UPS’S TO «OFF») TO «NORMAL OPERATING» (LOADS 2.1. USING THIS MANUAL.
-
Page 4: Acknowledgement Letter
We remain at you entire disposal for any further information or any query you should wish to make. Yours sincerely. SALICRU The equipment here described can cause important • physical damages due to wrong handling. -
Page 5: Safety Information
2. SAFETY INFORMATION 2.1. USING THIS MANUAL 2.2. ADDITIONAL SAFETY WARNINGS. The generic documentation for the unit is provided in digital Bypass panels should be considered as transformers or dis- • format on a pen drive and includes, among other documents, tribution lines from the point of view of electrical installa- the system user manual itself and document EK266*08 relating tion and safety. -
Page 6: Quality Assurance And Standards
The manufacturer shall not be held responsible for any damage caused by the user altering or tampering with the unit in any way. The EC declaration of conformity for the product is avail- able for the customer and can be requested from our head office. SALICRU... - Page 7 4. DESCRIPTION Static bypass The manual bypass is an optional peripheral for the UPS • input line that allows the power supply source for the loads to be MANUAL Input line selected from the UPS or directly from the commercial BYPASS PANEL network.
-
Page 8: Product Definition
ADAPT ADAPT-X ADAPT2 CUBE3+ Unit series for which the panel is intended. CUBE4 X-TRA X-PERT TWIN PRO2 With overlapping. Manual bypass. Exclusive protection panel with no manual bypass. Number of parallel units. Disregard for a single unit. SALICRU... -
Page 9: To Be Considered In The Installation
5. INSTALLATION Read and follow all of the Safety Information set out could be affected, although the order would be maintained. • or linked in chapter 2 of this document. Failure to adhere to any of the indications set out may cause a serious Depending on the power of the bypass panel and the version •... -
Page 10: Unit Reception
(single-phase or three-phase), the number of terminals on each block may vary. Connect the cables to the corre- sponding terminals according to each case, respecting the order of the phase (R) or phases (R-S-T) and neutral (N). SALICRU... - Page 11 order of the phase (R) or phases (R-S-T) and neutral (N), When there are discrepancies between the labels • indicated on the unit’s labels and in this manual. and the instructions in this manual, the labels on the unit will always take precedence. 5.3.5.
- Page 12 (*) Aux. (*) Aux. cont., available on manual bypass panels for these UPSs: SLC ADAPT SLC ADAPT-X SLC ADAPT2 SLC CUBE 3+ SLC CUBE 4 SLC TWIN PRO2 SLC X-PERT SLC X-TRA cont. (1) The IDIG4 input must be programmed as an auxiliary contact for the NC output circuit breaker.
- Page 13 The auxiliary terminals of the UPS are identified as follows, 5.3.7.3. Connection between the auxiliary contact of the depending on the product series: output switch on each UPS and those of the bypass panel (only available on panels from the SLC CUBE3+, of (JP5).
- Page 14 ••• INPUT OUTPUT Aux. cont. output Aux. cont. manual bypass (*) Aux. cont., available on manual bypass panels for these UPSs: (*) Aux. cont. SLC ADAPT SLC ADAPT-X SLC ADAPT2 SLC TWIN PRO2 SLC X-PERT SLC X-TRA UPS 1 (1) The IDIG4 input must be programmed as an auxiliary contact for the NC output circuit breaker.
- Page 15 STATIC BYPASS OUTPUT Aux. cont. output (*) Aux. cont., available on manual bypass panels for these UPSs: Aux. cont. manual bypass (*) Aux. cont. SLC ADAPT SLC ADAPT-X SLC ADAPT2 SLC X-PERT SLC X-TRA UPS 1 (1) The IDIG4 input must be programmed as an auxiliary contact for the NC output circuit breaker.
- Page 16 SREG_LOGIC_POS_NEG__DIG_ALMS_BOOLSET Boolset logic definition Positive(0)/Negative(1) SALICRU...
-
Page 17: Startup And Shutdown
6. START UP AND SHUTDOWN. These instructions are generic for any manual bypass panel Make sure that all the loads are shutdown (start up • • of this series, parallel and redundant equipments included. switches turned «Off»). Omit those manoeuvring of the switches that your unit doesn’t have. - Page 18 • procedure stated in the «User’s, installation and start up isolation, resulting in a risk of electrocution or short-circuit in manual» of the UPS. case of turning on any of the panel switches. SALICRU...
- Page 19 6.3.2. Manual bypass panel with two or more UPS’s. 6.4. SHIFTING FROM «MAINTENANCE OPERATING» (LOADS SUPPLIED THROUGH THE MANUAL BYPASS) TO Put all the UPS’s on bypass (inverters «Off»), according «NORMAL OPERATING» (LOADS SUPPLIED BY THE UPS • OR UPS’S). to the procedure stated in the «User’s, installation and start up manual»...
- Page 20 «Off». In case of including the separate by- pass line (-B), turn the «STATIC BYPASS» switch of the bypass panel «Off» too. In the illustration of Fig. 9, it is shown the position of switches once the manoeuvring has been done. SALICRU...
- Page 21 : ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................USER'S MANUAL...
- Page 22 Avda. de la Serra 100 08460 Palautordera BARCELONA Tel. +34 93 848 24 00 Fax +34 93 848 22 05 services@salicru.com SALICRU.COM The Technical Service and Support (T.S.S.) network, Com- mercial network and warranty information are available in website: www.salicru.com...
