7.4.5. Rated values menu.
Rated
User
Rated Input voltage
Rated Input frequency
Rated output voltage
Rated output frequency
Measurements Alarms Status & Ops
Rated
User
40
Number of Batteries
24 Ah
Capacity (Ah)
2.25 V
Float / Fast cell / Cell
2.35 V
Measurements Alarms Status & Ops
Configuration menu for the Rated Battery parameters:
Number of batteries in each half-bus, positive and negative
•
(40 = 20 + 20)
Battery charge current with respect to battery capacity
•
(If C = 24 Ah, Charge Current = 0.2 x 24 = 4.8 A)
7.4.6. Charts menu.
Charts
User
Not available
Measurements Alarms Status & Ops
7.4.7. Advanced menu
User
Start menu
ON/OFF
Measurements Alarms Status & Ops
USER MANUAL
0/1
S3.3
Start
4-PM
Input / Output
230 V
Batteries
50 Hz
230 V
50 Hz
Ratings Charts Advanced
0/1
S3.3
Start
4-PM
Input / Output
0.2 x C
Charging current
Batteries
1.75 V
F.A@0.15 x C
1.65 V
F.A@0.6 x C
Ratings Charts Advanced
0/1
S3.3
Start
4-PM
Ratings Advanced
Charts
0/1
S3.3
Start
4-PM
Config Start
Config. Power
UPS Flags
PM Flags
0
Ratings Charts Advanced
Configuration menu for the Rated Voltage and Frequency param-
eters.
Rated input voltage in volts.
•
Rated input frequency in Hz.
•
Rated output voltage in volts
•
Rated output frequency in Hz.
•
Battery capacity in Ah.
•
Float Voltage per cell in Volts [Half-bus Float Voltage = 40
•
(batteries) / 2 (half-buses) x 6 (cells/battery) x 2.25 (V/cell)
= 270 Volts].
End of Backup Voltage at a discharge current of 0.15 x C
•
per cell in Volts [Half-bus EOD Voltage @ 0.15 x C = 40 (bat-
teries) / 2 (half-buses) x 6 (cells/battery) x 1.75 (V/cell) =
210 Volts].
End of Backup Voltage at a discharge current of 0.6 x C per
•
cell in Volts [Half-bus EOD Voltage @ 0.6 x C = 40 (batteries)
/ 2 (half-buses) x 6 (cells/battery) x 1.65 (V/cell) = 198 Volts].
Fast Charge Voltage per cell in Volts [Half-bus Fast Charge
•
Voltage = 40 (batteries) / 2 (half-buses) x 6 (cells/battery) x
2.35 (V/cell) = 282 Volts].
Charts screen.
Configuration menu for the Start Screen.
When the Config on Start button is pressed, a 1 appears in the
cell to the right. If the UPS is turned off under these conditions,
the next time it is turned on, the user will have to enter the Rated
Voltage and Frequency, Date and Time, and Language. Once
these parameters have been set, the value Config on Start will
be reset to zero.
