2. SAFETY INFORMATION.

2.1. USING THIS MANUAL.

The latest version of the device's user manual is available to The latest version of the device's user manual is available to
the customer for download on our website (www.salicru.
the customer for download on our website
com). It is necessary to read it carefully before performing any com) . It is necessary to read it carefully before performing any
actions, procedures or operations on it. actions, procedures or operations on it.
The purpose of the user manual is to provide information about The purpose of the user manual is to provide information about
safety and the procedures for device installation and operation. safety and the procedures for device installation and operation.
Read them carefully and follow the steps indicated in the order Read them carefully and follow the steps indicated in the order
established. established.
The "Safety Instructions"
plied with this device. Compliance
tions is obligatory, with the user being legally
responsible
for observing and applying them.
The device is delivered properly labelled for correct identifica-
tion of each of its parts, which, together with the instructions
described in this user manual, allows installation and start-up
operations to be performed in a simple and organised manner
without any doubts whatsoever.
However, because the product is constantly evolving,
discrepancies or slight contradictions may arise. If in
any doubt, the labelling on the device itself will always
prevail.
Once the device is installed and operating, it is recommended
to keep all of the documentation in a secure place for future
reference.
This user manual applies to the SLC ADAPT 2, series con-
sisting of cabinets with 24, 33 and 42U of height and with 10
and 15 kVA modules, with the following configurations:
24U cabinets: with 2 or 4 slots that allow them to hold up
•
to 4 x 10 kVA modules or 3 x 15 kVA modules (*).
33U cabinets: with 2, 4 or 6 slots that allow them to hold
•
up to 6 x 10 kVA modules or 6 x 15 kVA modules (*).
42U cabinets: with 2, 4 or 6 slots that allow them to hold
•
up to 6 x 10 kVA modules or 6 x 15 kVA modules (*).
(*) 10 kVA modules: degrade to 6 kVA/FPout = 1.
(*) 15 kVA modules: degrade to 9 kVA/FPout = 1 when
operating with a three-phase input of 3x220 V or 3x208 V.
The housings are 19" rack cabinets, which may or may not
share the space with the batteries.
While the customer can perform these adaptations on their
own or otherwise, we can also manufacture any configuration
on demand.
When a system differs from that shown in the figures in
Chapter , except when it differs in the number of mod-
ules connected in parallel and/or the technical specifi-
cations are modified, additional explanatory annexes
will be published if deemed appropriate or necessary.
These will be supplied in printed format with the device.
The following terms are used interchangeably in the document
to refer to:
USER MANUAL
(www.salicru.
document EK266*08 is sup-
with these instruc-
'SLC ADAPT 2, ADAPT 2, UPS, system, device or
•
unit'.- ADAPT2 series of Uninterruptible Power Supplies.
Depending on the context of the phrase, it can refer either
to the actual UPS itself or to the UPS and the batteries,
regardless of whether or not it is all assembled in the same
metal enclosure.
'Batteries' or 'accumulators'.- Bank or set of elements
•
for storing the flow of electrons by electrochemical means.
'T.S.S.'.- Technical Service and Support.
•
'Customer', 'installer,' 'operator' or
•
used interchangeably, and by extension can refer to the in-
staller and/or operator who will carry out the corresponding
actions, while this same person may be responsible for car-
rying out the respective actions when acting on behalf or in
representation of the first.
2.1.1. Conventions and symbols used.
Some symbols may be used and appear on the device, batteries
and/or in the context of the user manual.
For more information, see Section 1.1.1 of the
tions' document EK266*08.
In the event that there are differences in relation to the safety
instructions between document EK266*08 and the user's
manual of the device, the latter will always prevail.
2.1.2. Safety considerations.
While safety-related considerations will be dealt with in
•
more detail in Chapter , the following must be taken into
account:
Inside the battery cabinet there are accessible parts with
ˆ
HAZARDOUS VOLTAGE and consequently risk of electric
shock, so they are classified as RESTRICTED ACCESS
ZONES. Therefore, the key of the battery cabinet will
not be available to the OPERATOR or USER, unless such
person has been properly instructed.
In case of intervention inside the battery cabinet either
during the connection, preventive maintenance or re-
pair procedures, it must be taken into account that
voltage of the battery set exceeds 200 V
appropriate safety measures must be taken.
Any operation of connecting and disconnecting the ca-
ˆ
bles or handling inside a cabinet will not take place for
around 10 minutes in order to allow the internal dis-
charge of the capacitors of the device. Even so, check
with a multimeter that the voltage at terminals is less
than 36 V.
In case of installation in neutral IT mode, the switches,
ˆ
circuit breakers and thermal magnetic protection must
cut the NEUTRAL in addition to the three phases.
'user'.- These are
'Safety Instruc-
the
DC, so
