7.4.3. UPS alarms menu.
User
Measurements Alarms
User
No. Description
Input Volt. Detected
1
2
Input Volt. Detected
3
No Output
4 No Output
5
Input Volt. Detected
Measurements Alarms
7.4.4. Status & Ops menu.
User
UPS
Battery
Modules
Measurements Alarms
Manual operations buttons, password-protected for Advanced
users:
Switch BYP: Switch to Bypass mode.
•
Switch INV: Switch to Inverter mode.
•
Extract Module: Button to allow extraction of modules.
•
Unlock: UPS Unlock button.
•
Boost / Float: Button to switch manually from Float Charging
•
to Fast Charge, or vice versa.
Battery test: Button to manually initiate a battery test.
•
Batt. Maint.: Button for maintenance discharge test.
•
Stop test: Button to manually stop any of the above tests.
•
UPS:
NO OUTPUT: Message that is displayed when the UPS is
•
started-up.
IN BYPASS: Displayed when the UPS is in Bypass mode.
•
INV.RUNNING: The Inverter is running.
•
IN INVERTER: The UPS is operating in Inverter mode.
•
BYP.LOCKED: The UPS is locked in Bypass mode. This re-
•
quires manual unlocking.
OUT.LOCKED: The UPS is locked with no output. This requires
•
manual unlocking.
44
0/1
Alarms
S3.3
4-PM
Page 1 1
Status & Ops Ratings Charts
0/1
Log
S3.3
4-PM
Date Est. UPS Est>> Bat
INV READY
31 / 1 / 2019 NO LOAD
0:15: 0
31 / 1 / 2019 INV READY NO LOAD
0:15: 0
31 / 1 / 2019 INV READY NO LOAD
00:14: 58
31 / 1 / 2019
NO LOAD
NO OUTPUT
00:14: 53
31 / 1 / 2019
NO OUTPUT NO LOAD
00:14: 53
Status & Ops Ratings Charts
0/1
Status & Ops.
S3.3
4-PM
IN INVERTER
FLOAT [BT NO]
MODs DETECTED (4/4)
Status & Ops Ratings Charts
Screen with a table listing the Active Alarms for the UPS (red
Start
text) and Active Warnings for the UPS (yellow text).
Log
Button to silence the acoustic alarm and vertical scroll controls in
case there are many alarms.
See the tables of Alarms and Warnings for the Alarms and
Warnings that may appear in this menu.
Advanced
Screen showing the Events log with the following information
Start
in columns:
Event number
Back
•
Description
•
Date and time of event
•
State of the UPS
•
Page
Battery status
•
1 5
The events log store information on Alarms, Warnings and
Events. See the tables of Alarms, Warnings and Events.
Events
1 20
Advanced
Battery status message:
Start
NO BATTERY: No batteries are connected to the UPS.
•
BYP Transf.
FLOATING: Batteries are float-charging.
•
INV Transf.
FAST: Batteries are fast-charging.
•
Extract Mod.
DISCHARGE: Batteries are Discharging.
•
Unlock
STOP CHARGE: Temporary pause in battery charging.
•
Boost / Float
END BCKUP: End of backup.
•
Battery Test
TEST: Battery test.
•
Batt. Maint.
MAINT.: Maintenance discharge test.
•
Stop test
Battery test results message:
Advanced
[BT NO]: No battery test has been performed since the last
•
time the UPS was started-up.
[BT ..]: Test running.
•
[BT OK]: Result of the latest test: OK.
•
[BT KO]: Result of the latest test: fault.
•
Modules:
MOD START: No modules detected.
•
MOD DETECTED (n): Normal message: number of modules
•
feeding the UPS output.
MODULE OFF: Appears when the module disconnection
•
button is pressed.
MOD EXTRACTED: Appears when a module is correctly ex-
•
tracted.
MOD INSERTED: Appears when a new module is correctly
•
inserted.
MOD EXTRACT INC: Appears when a module is incorrectly
•
extracted.
