Fig. 5. Front views of the 42U cabinet, with the door
closed (left), with the door open and 2 modules
installed (centre) and rear view with protective
cover removed (right).
10
Communications interface
Disconnector
Manual Bypass (Optional)
(See ) + Bypass Module
Terminal block, See
Battery
Isolator
Switch
Power
modules
External
battery
terminals
Manual
Bypass
Terminals
(Optional)
Detail A, page 7
