Open-Q™ 670 HDK Hardware Development Kit User Guide Version 1.0
Pin# Signal
A23 MIPI_CSI2_LANE1_N
A24 MIPI_CSI2_LANE1_P
A25 DGND
A26 MIPI_CSI2_LANE0_N
A27 MIPI_CSI2_LANE0_P
A28 DGND
A29 MIPI_CSI2_CLK_N
A30 MIPI_CSI2_CLK_P
Pin# Signal
C1 CAM_MCLK0_BUF
C2 CAM0_RSTN
C3 CAM_ELDO9_EN
C4 DGND
C5 CAM1_RSTN
C6 CAM_ELDO3_EN
C7 CAM_MCLK1_BUF
C8 DGND
C9 CAM2_RSTN
C10 CAM_MCLK2_BUF
C11 CAM_ELDO2_EN
C12 DGND
C13 CAM_MCLK3_BUF
C14 CAM3_RSTN
C15 OIS_SYNC
C16 DGND
C17 LASER_IRQ
C18 LASER_CE
C19 DGND
C20 P2V8_CAMA3
C21 P2V8_VCM_LASER_
RF
C22 DGND
C23 CAM_IRQ
Description Pin#
CSI2 data B23
CSI2 data
B24
B25
CSI2 data B26
CSI2 data
B27
B28
CSI2 clock
B29
CSI2 clock B30
Description Pin#
SDA GPIO13 D1
SDA GPIO80 D2
SDA GPIO79 D3
D4
SDA GPIO28
D5
SDA GPIO27
D6
SDA GPIO14
D7
D8
SDA GPIO9
D9
SDA GPIO15 D10
SDA GPIO8 D11
D12
SDA GPIO16 D13
SDA GPIO23 D14
SDA GPIO25 D15
D16
SDA GPIO26 D17
SDA GPIO100 D18
D19
NC D20
2.8V power supplier
D21
D22
SDA GPIO24
D23
32
Copyright Intrinsyc Technologies Corporation
Signal
P2V85_AVDD_CAM1_2
P2V85_AVDD_CAM1_2
DGND
P2V8_VCM_LASER_RF
P2V8_VCM_LASER_RF
DGND
P1V2_DVDD_CAM1_2
P1V2_DVDD_CAM1_2
Signal
DGND
MIPI_CSI0_LANE3_N
MIPI_CSI0_LANE3_P
DGND
MIPI_CSI0_LANE2_N
MIPI_CSI0_LANE2_P
DGND
MIPI_CSI0_LANE1_N
MIPI_CSI0_LANE1_P
DGND
MIPI_CSI0_LANE0_N
MIPI_CSI0_LANE0_P
DGND
MIPI_CSI0_CLK_N
MIPI_CSI0_CLK_P
DGND
MIPI_CSI1_LANE3_N
MIPI_CSI1_LANE3_P
DGND
MIPI_CSI1_LANE2_N
MIPI_CSI1_LANE2_P
DGND
MIPI_CSI1_LANE1_N
Description
2.85V power
supplier
2.85V power
supplier
2.8V power
supplier
2.8V power
supplier
1.2V power
supplier
1.2V power
supplier
Description
CSI0 data
CSI0 data
CSI0 data
CSI0 data
CSI0 data
CSI0 data
CSI0 data
CSI0 data
CSI0 clock
CSI0 clock
CSI1 data
CSI1 data
CSI1 data
CSI1 data
CSI1 data
