Open-Q™ 670 HDK Hardware Development Kit User Guide Version 1.0
Subsystem /
Feature Set
Connectors
GNSS via SDR670 –Qlink
Qualcomm Proprietary
Protocol
RF 2xWLAN / BT
1x GNSS
Audio 1 x Headset Output
2 x Loud-speaker
1 x Earpiece output
3 x analog MICs
3 x digital MICs
Camera 3 x MIPI CSI
Display 1 x MIPI DSI + Touch
100-pin display Connector
USB 1 x Type-C USB 3.1
Connectors 2 x 240pin BB Card
connector
Description
GNSS Frontend
Connect to antenna on carrier board
via coax cable
Connect to antenna on carrier board
via coax cable
Headset/ headphone output
2 x loud-speaker output
Earpiece output
Analog MIC input
Digital MIC input
1x 120pin Camera Connector for
CSI0, CSI1, and CSI2
100- pin display connector
Type-C USB 3.1
Connector for BB Card
15
Copyright Intrinsyc Technologies Corporation
Specification
GPS/ GLONASS/
COMPASS/Galileo
2.4/ 5 GHz
GPS/ GLONASS/
COMPASS /Galileo
Analog differential output
Digital output
Analog differential output
Analog differential input
Digital input
MIPI Allie Specification
v1.2
MIPI Allie Specification
v1.2.
MIPI D-PHY Specification
v0.65, v0.81, v0.90,
v1.01 ,v1.2
USB3.1
2 x 240 pin B2B connector
