Open-Q™ 670 HDK Hardware Development Kit User Guide Version 1.0
Domain
GNSS Antenna
LED
LCD Display and Touch
connector
Sensor header
SIM Card
CSI Camera connectors
The following sections provide in depth information on each expansion headers and connectors
on the carrier board. The information listed below is of particular use for those who want to
interface other external hardware devices with the Open-Q 670 HDK. Before connecting
anything to the development kit, please ensure the device meets the specific hardware
requirements of the processor.
Description
PCB Antenna
3xLED
100 pin for LCD signals
from B2B boards for display
24 pin sensor header
WWAN SIM card connector
(Reserve)
1 x 120pin connector with
MCLK, GPIOS, CCI
1 x 120pin connector with
MCLK, GPIOS, CCI
20
Copyright Intrinsyc Technologies Corporation
Specification
GPS :
1574.42 MHz – 1576.42
MHz
GLONASS :
1587 MHz – 1606 MHz
COMPASS: 1559.05 to
1563.14MHz
Galileo: 4.092MHz
BW(centered on
1575.42MHz)
Red : PMIC Driven
Green: PMIC Driven
Blue: PMIC Driven
4-lane MIPI DSI0 , DSI1
I2C/SPI/GPIO
Backlight
MIPI Allie Specification v1.2
MIPI D-PHY Specification
v0.65,v0.81, v0.90, v1.01,
V1.2
MIPI C-PHY Specification
v1.0
24 pin sensor header
2x 4bit Micro SIM card
support
Supports CSI0, CSI1 and
CSI2 via one 120pin
connector
▪ 3 x MIPI-CSI each 4 lane
▪ External flash driver
control
▪ Support for 3D camera
configuration
▪ Separate MCLK / CCI
control
MIPI Allie Specification v1.2
for Camera Serial Interface
Usage
Antenna to BB card
Red : General
purpose
Green : General
purpose
Blue : General
purpose
Only 1 lane DSI is
supported on
HDK670
Header to connect
sensor board.
For WWAN mini
PCI express cards
(for internal use only
– not supported)
▪ Single Rear,
Front camera
▪ Dual Camera
▪ Iris Camera
