1.4

Accessories

1.4.1

Reference Design

The Mars XU3 SoC module reference design features an example configuration for the Zynq Ultrascale+
MPSoC device, together with an example top level HDL file for the user logic.
A number of software applications are available for the reference design, that show how to initialize the
peripheral controllers and how to access the external devices. Pre-compiled binaries are included in the
archive, so that the user can easily check that the hardware is functional.
The reference design can be downloaded from the Enclustra download page [2].
1.4.2

Enclustra Build Environment

The Enclustra Build Environment (EBE) [15] enables the user to quickly set up and run Linux on any Enclustra
SoC module or system board. It allows the user to choose the desired target, and download all the required
binaries, such as bitstream and FSBL. It downloads and compiles all required software, such as U-Boot, Linux,
and BusyBox based root file system.
The Enclustra Build Environment features a graphical user interface (GUI) and a command line interface (CLI)
that facilitates the automatic build flow.
The Enclustra Build Environment How-To Guide [16] describes in more detail how to use the EBE to customize
the provided software for the user application. The document provides information on the configuration
options for U-boot, Linux kernel and Buildroot, debugging possibilities for Linux applications, customization
of device trees and integration of existing or new kernel drivers.
1.4.3

Mars PM3 Base Board

The current Mars PM3 base board revision does not support the Mars XU3 SoC module. Please contact
Enclustra for further information.
1.4.4

Mars EB1 Base Board

Mars 200-pin SO-DIMM socket
2 Mini Camera Link connectors (requires FPGA support)
HDMI 1.3 connector (requires FPGA support)
40-pin GPIO connector (Anios)
3 12-pin GPIO connector (two of the connectors with Pmod™ compatible pinout)
RJ45 Ethernet connector
USB 2.0 A host connector
Micro USB 2.0 device connector (shared)
FTDI USB 2.0 device controller with micro USB device connector
microSD card holder
Various switches and LEDs
Integrated Xilinx compatible JTAG adapter
Single 12 V DC supply voltage or USB bus-powered (with restrictions)
Form factor: 120
Please note that the available features depend on the equipped Mars module type.
D-0000-432-001
80 mm
8 / 52 Version 04, 25.07.2019
