5 Operating Conditions

5.1

Absolute Maximum Ratings

Table 41 indicates the absolute maximum ratings for Mars XU3 SoC module. The values given are for ref-
erence only; for details please refer to the Zynq UltraScale+ MPSoC, DC and AC Switching Characteristics
Datasheet [21].
Symbol
Description
VCC_MOD
Supply voltage relative to GND
VCC_3V3
3.3 V supply voltage relative to GND
VCC_BAT
Supply voltage for MPSoC battery-backed RAM and
battery-backed RTC
VCC_IO_B26
Output drivers supply voltage relative to GND
VCC_CFG_MIO
Output drivers supply voltage relative to GND
VCC_IO_B65
Output drivers supply voltage relative to GND
V_IO
I/O input voltage relative to GND
V_ADC
Analog I/O input voltage for the ADC
Temperature range for commercial modules (C)
Temperature
Temperature range for industrial modules (I)
Table 41: Absolute Maximum Ratings
D-0000-432-001
*
*
47 / 52
Rating
Unit
-0.5 to 6
V
-0.5 to 3.6
V
0 to 3.6
V
-0.5 to 3.4
V
-0.5 to 3.63
V
-0.5 to 2.0
V
-0.5 to V
+0.55
V
CCO
-0.5 to 2.3
V
0 to +70
C
-40 to +85
C
Version 04, 25.07.2019
