1.4

Accessories

1.4.1

Reference Design

The Mars AX3 FPGA module reference design features an example configuration for the Artix-7 FPGA de-
vice, together with an example top level HDL file for the user logic.
A number of software applications are available for the reference design, that show how to initialize the
peripheral controllers and how to access the external devices. Pre-compiled binaries are included in the
archive, so that the user can easily check that the hardware is functional.
The reference design can be downloaded from Github: https://github.com/enclustra.
1.4.2

Enclustra Heat Sink

For Mars modules an Enclustra heat sink is available for purchase along with the product. Please refer to
section 2.10.6 for further information on the available cooling options.
1.4.3 Mars ST3 Base Board
Mars 200-pin SO-DIMM socket
MIPI D-PHY connector (requires FPGA support)
Mini DisplayPort connector (requires FPGA support)
HDMI connector (requires FPGA support)
USB 3.0 host connector
RJ45 Ethernet connector
2 40-pin GPIO connector (Anios)
1 8-pin and 1
FTDI USB 2.0 device controller with micro USB device connector
microSD card holder
User LEDs
Integrated Xilinx compatible JTAG adapter
Support for low I/O voltages (1.2 V, 1.8 V)
Single 12 V DC supply voltage
Form factor: 100
Please note that the available features depend on the equipped Mars module type.
1.4.4

Mars EB1 Base Board

Mars 200-pin SO-DIMM socket
2 Mini Camera Link connectors (requires FPGA support)
HDMI 1.3 connector (requires FPGA support)
40-pin GPIO connector (Anios)
3 12-pin GPIO connector (two of the connectors with Pmod™ compatible pinout)
RJ45 Ethernet connector
USB 2.0 A host connector
Micro USB 2.0 device connector (shared)
FTDI USB 2.0 device controller with micro USB device connector
microSD card holder
Various switches and LEDs
Integrated Xilinx compatible JTAG adapter
Single 12 V DC supply voltage or USB bus-powered (with restrictions)
Form factor: 120
Please note that the available features depend on the equipped Mars module type.
D-0000-426-004
4-pin GPIO connectors (Pmod™ compatible pinout)
80 mm
80 mm
