Module
Mars XU3 SoC module
Table 36: Product Information

Module Configuration

Addr. Bits Comment
7-4 MPSoC type
0x08
3-0 MPSoC device speed grade
7-6 Temperature range
5 Power grade
0x09
4-3 Gigabit Ethernet port count
2-0 Reserved
7-2 Reserved
0x0A
1-0 USB 2.0 port count
7-4 DDR4 RAM size (GB)
0x0B
3-0 QSPI flash memory size (MB)
7-4 eMMC flash size (GB)
0x0C
3-0 Reserved
Table 37: Module Configuration
The memory sizes are defined as Resolution 2
DRAM=2: 2 GB, DRAM=3: 4 GB, etc).
Table 38 shows the available MPSoC types.
Value MPSoC Device Type
0 XCZU3EG ES
1 XCZU2EG
2 XCZU2CG
3 XCZU3EG
Table 38: MPSoC Device Types
Table 40 shows the available MPSoC speed grades.
D-0000-432-001
Product Family Reserved
0x0330 0x[XX]
Min. Value
0
0
0
0 (Normal)
0
-
-
0
0 (0 GB)
0 (0 MB)
0 (0 GB)
-
(Value-1)
(e.g. DRAM=0: not equipped, DRAM=1: 1 GB,
45 / 52
Revision

Product Information

0x[YY] 0x0323 [XX][YY]
Max. Value Comment
3 See MPSoC type table
(Table 38)
3 See MPSoC speed grade
table (Table 39)
2 See temperature
range table (Table 40)
1 (Low power)
1
-
-
1
3 (4 GB) Resolution = 1 GB
7 (64 MB) Resolution = 1 MB
5 (16 GB) Resolution = 1 GB
-
Version 04, 25.07.2019
