Features

1
1.1
1.2
4/44
Downloaded from Elcodis.com electronic components distributor
Features
●
Four 5 V power supply options:
– Power jack
– ST-LINK/V2 USB connector
– User USB connector
– Daughterboard
●
Audio speaker and microphone connected to DAC and ADC of STM32L152VBT6
●
2 GByte or more SPI interface MicroSD Card
●
I2C compatible serial interface temperature sensor
● RS-232 communication
● IrDA transceiver
● JTAG and trace debug support, ST-LINK/V2 embedded.
● 240x320 TFT color LCD connected to SPI interface of STM32L152VBT6
●
Joystick with 4-direction control and selector
●
Reset button
●
Tamper or Key button
●
4 color user LEDs and 3 LEDs as MCU power range indicator
●
MCU consumption measurement circuit
●
LCD glass 32 x 4 segments connected to LCD controller in STM32L152VBT6
● Extension connector for daughterboard or wrapping board
● MCU voltage choice of 3.3 V or adjustable from 1.65 V to 3.6 V
● USB FS connector
● Two touch sensing buttons
●
Light dependent resistor (LDR)
●
Potentiometer

Demonstration software

Demonstration software is preloaded in the board's Flash memory for easy demonstration of
the device peripherals in stand-alone mode. For more information and to download the
latest version available, please refer to the STM32L152-EVAL demonstration software
available on www.st.com.

Order code

To order the STM32L152VBT6 evaluation board, use the order code STM32L152-EVAL.
TM
Doc ID 18141 Rev 1
UM1018
