BNC connector CN13
Figure 12. Analog input connector CN13 (viewed from bottom)
Table 22.
Analog input connector CN13
Pin number
Description
1
GND
2
GND
3
GND
Pin number
4
5
Doc ID 18141 Rev 1
Connectors
Description
GND
Analog input PA5
27/44
