Features

•
STM32L476ZG microcontroller with 1-Mbyte flash memory and 128-Kbyte RAM
• Four power supply options: power jack, ST-LINK/V2-1 USB connector, USB OTG FS
connector, daughterboard
•
Microcontroller supply voltage: 3.3 V or range of 1.71 to 3.6 V
•
Two MEMS digital microphones
•
Two jack outputs for stereo audio headphones with independent content
•
Slot for microSD™ card supporting SD, SDHC, SDXC
• 4-Gbyte microSD™ card bundled
•
16-Mbit (1M x 16 bit) SRAM device
•
128-Mbit (8M x 16 bit) NOR flash memory device
•
256-Mbit Quad-SPI flash memory device with double transfer rate (DTR) support
•
RF-EEPROM with I
• EEPROM supporting 1 MHz I
•
RS-232 port configurable for communication or MCU flashing
•
IrDA transceiver
•
USB OTG FS Micro-AB port
•
CAN 2.0A/B-compliant port
• Joystick with four-way controller and selector
•
Reset and wake-up/tamper buttons
•
Touch-sensing button
•
Light-dependent resistor (LDR)
•
Potentiometer
•
Coin battery cell for power backup
•
LCD glass module daughterboard (MB979) with 40x8-segment LCD driven directly by
STM32L476ZG
•
2.8-inch 320x240 dot-matrix color TFT LCD panel with resistive touchscreen
•
Smartcard connector and SWP support
•
NFC transceiver connector
• Connector for ADC input and DAC output
•
Power-metering demonstration with dual-channel sigma-delta modulator
•
PT100 thermal sensor with dual-channel sigma-delta modulator
•
MCU current consumption measurement circuit
•
Access to the comparator and operational amplifier of STM32L476ZG
•
Extension connector for motor control module
•
JTAG/SWD, ETM trace debug support, user interface through USB Virtual COM port,
embedded ST-LINK/V2-1 debug, and flashing facility
•
Extension connector for the daughterboard
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
²
C bus
²
C-bus communication speed
UM1855 Rev 6
Features
(a)
