Hardware and layout
2.10
2.11
Note:
2.12
12/44
Downloaded from
Elcodis.com
electronic components distributor
Table 8.
RS-232 and IrDA related jumpers (continued)
Jumper
USART2_CTS is connected to RS-232 transceiver when JP9 is set as shown
(default setting).
JP9
Bootloader_RESET is connected to RS-232 transceiver when JP9 is set as
shown.
USART3
JP7,JP8 Refer to
Table 6
for
JP6
See
Table 5
for Bootloader_BOOT0 settings.
Touch sensing buttons
The STM32L152-EVAL evaluation board supports two touch sensing buttons based on
either charge transfer technology (default) or RC charging.
RC charging technology can be enabled by modifying the board:
1.
Remove R29.
2.
Mount resistors R22 (1 MOhm), R23 (1 MOhm), R24 (10 KOhm) and C18(1 nF).
MicroSD Card
The 2 GB (or more) MicroSD Card connected to SPI2 port of the STM32L152VBT6 is
available on the board. MicroSD Card detection is managed by standard I/O port PE6.
JP2 must be kept on open for trace purposes (connected to CN8).
Table 9.
MicroSD Card related jumpers
Jumper
PE6 is connected to MicroSD Card detection when JP2 is closed (default setting).
JP2
PE6 is disconnected from MicroSD Card detection but remains connected to trace
connector CN8 when JP2 is open.
Analog input
A BNC connector, CN13, is connected to PA5 of the STM32L152VBT6 as external analog
input or DAC output. The 50 ohm terminal resistor can be enabled by closing the solder
bridge SB5. A low pass filter can be implemented for the BNC connector by replacing R47
and C31 for ADC input or replacing R45 and C31 for DAC output with the values requested
by end user's application.
There are also 3 analog signals available on the board:
1.
10 KOhm potentiometer RV3 connected to PB12.
2.
IDD measurement output signal connected to PA5 for MCU power consumption test.
3.
External ADC input which can be connected to TP3 (AIN+) and TP2 (AIN-), R48 should
be removed to reduce the noise on this analog input.
Description
settings.
Description
Doc ID 18141 Rev 1
UM1018
Setting
1
2
3
1
2
3
