Overview

1
1.1
1.2
1.3
6/61
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Overview

Features

•
Four 5 V power supply options: Power jack, ST-LINK/V2 USB connector, User USB
connector or daughter board
2
•
I S Audio DAC, stereo audio jack which supports headset with microphone
•
2-Gbyte or more SPI interface microSD card
2
•
I C compatible serial interface temperature sensor, EEPROM and RF EEPROM
•
RS232 and RS485 communication
•
IrDA transceiver
•
JTAG/SWD and ETM trace debug support, ST-LINK/V2 embedded
•
1-Mbit SPI serial Flash memory
•
240x320 TFT color LCD connected to the SPI interface
• Joystick with 4-direction control and selector
• Reset, Tamper or Key button
• 4-color user LEDs and high brightness LED
• Humidity sensor
• Extension connectors for daughter board or wrapping board
•
MCU voltage choice: 3.3 V or adjustable from 2.0 V to 3.6 V
•
USB FS connector
•
Touch-sensing buttons
•
RTC with backup battery
•
CAN2.0A/B compliant connection
•
Light-dependent resistor (LDR)
•
IR LED and receiver
•
Potentiometer
•
2 motor control connectors

Demonstration software

The demonstration software is preloaded in the board's Flash memory for an easy
demonstration of the device peripherals in standalone mode. For more information and to
download the latest version available, please refer to the STM32303E-EVAL demonstration
software available on www.st.com.

Order code

To order the STM32F303VET6 evaluation board, use the STM32303E-EVAL order code.
DocID026738 Rev 1
UM1807
