Connectors
3.11
26/44
Downloaded from Elcodis.com electronic components distributor
Table 20. Trace debugging connector CN8 (continued)
Pin number Description
17 GND
19 GND

MicroSD Card connector CN4

Figure 11. MicroSD Card connector CN4 (viewed from front)
Table 21. MicroSD Card connector CN4
Pin number Description
1
2 MicroSDcard_CS (PD7)
3 MicroSDcard_DIN(PB15)
4 +3V3
Pin number
18
20
Pin number
5
6
7
8
9
Doc ID 18141 Rev 1
UM1018
Description
TraceD2/PE5
TraceD3/PE6
Description
MicroSDcard_CLK (PB13)
Vss/GND
MicroSDcard_DOUT(PB14)
MicroSDcard_detect (PE6)
