Table 15. Daughterboard extension connector CN6 (continued)
Pin Description Alternative function
25 PD3 USART2_CTS
27 PD5 USART2_TX / LED4
29 PD7 CS_uSD
31 VLCD -
33 PB3 JTDO / COMP_POT-
35 PB5 TEMP_SMBAI / COMP_POT+
37 PB7 I2C_TEMP_SDA
39 GND -
41 PE2 LCD glass_SEG38 / TRACE_CLK Remove LCD glass U20
43 PE4 TRACE_D1
45 PB8 LCD glass_SEG16
47 PE6 TRACE_D3 / SD Card detection
49 D5V -
2 PC6 TS_KEY1
4 PC8 TS_SHIELD
6 PA8 LCD glass_COM0
8 PA10 LCD glass_COM2
10 GND -
12 PA11 USB DM
14 PA13 JTMS
16 PA14 JTCK
18 PC11 LCD glass_SEG41 / USART3_RX JP8 open
20 PA15 JTDI
22 PD0 LED1
24 PD2 LCD glass_SEG43
26 PD4 USART2_RTS/ LED3
28 PD6 USART2_RX
30 GND -
32 PH2 CS_LCD
34 PB4 JTRST / LDR
36 PB6 I2C_TEMP_SCL
38 PE0 LCD glass_SEG36
40 PE1 LCD glass_SEG37
42 PE3 LCD glass_SEG39 / TRACE_D0
How to disconnect with function block on
JP9 open
JP19 open
Remove SD card from CN4
-
JP17 open
JP17 and JP11 open
Remove R62
-
-
Remove LCD glass U20
JP2 open
-
Remove R14
-
Remove LCD glass U20
Remove LCD glass U20
-
Remove R16
-
-
-
Remove R111
Remove LCD glass U20
JP18 open
Remove R19
-
-
JP10 open
Remove R69
Remove LCD glass U20
Remove LCD glass U20
Remove LCD glass U20
