Connectors
22/44
Downloaded from Elcodis.com electronic components distributor
Table 15. Daughterboard extension connector CN6 (continued)
Pin Description Alternative function
44 PE5 TRACE_D2
46 PB9 LCD glass_COM3
48 +3V3 -
50 GND -
Table 16. Daughterboard extension connector CN7
Pin Description Alternative function
1 GND -
3 PD14 LCD glass_SEG34
5 PD12 LCD glass_SEG32
7 PD10 LCD glass_SEG30
9 PC13 IDD_CNT_EN
11 RESET# -
13 PB15 uSD_SPI2_MOSI
15 PB13 uSD_SPI2_SCK
17 PB11 LCD glass_SEG11
19 D5V
21 PE14 LCD_SPI1_MISO
23 PH0 OSC_IN
25 PE12 JOYSTICK_LEFT
27 PE10 JOYSTICK_DOWN
29 PE8 JOYSTICK_SEL
31 PE7 Audio_IN
33 PB1 LCD glass_SEG6
35 PC5 LCD glass_SEG23
37 PA7 LCD glass_SEG4
39 GND -
41 PA4 Audio_DAC1_out
43 PA2 LCD glass_SEG1
45 PC3 LCD glass_SEG21
47 PC1 LCD glass_SEG19
49 PC13 IDD_CNT_EN
2 PD15 LCD glass_SEG35
How to disconnect with function block on
-
Remove LCD glass U20
-
-
How to disconnect with function block
on STM32L152-EVAL board
-
Remove LCD glass U20
Remove LCD glass U20
Remove LCD glass U20
-
-
-
-
Remove LCD glass U20
-
Remove R57
Remove X2 from socket and close SB3
Remove R118
Remove R127
Remove R112
Remove R75
Remove LCD glass U20
Remove LCD glass U20
Remove LCD glass U20
-
Remove R103
Remove LCD glass U20
Remove LCD glass U20
Remove LCD glass U20
-
Remove LCD glass U20
Doc ID 18141 Rev 1
UM1018
STM32L152-EVAL board
