Connectors
3.6
3.7
3.8
24/44
Downloaded from
Elcodis.com
electronic components distributor
ST-LINK/V2 USB type B connector CN11
The USB connector, CN11, is used to connect the embedded ST-LINK/V2 to the PC for
board debugging.
Figure 8.
USB type B connector CN11 (viewed from front)
Table 17.
USB type B connector CN11
Pin number
1
VBUS (power)
2
DM
3
DP
User USB Type B connector CN1
Figure 9.
USB type B connector CN1 (viewed from front)
Table 18.
USB type B connector CN1
Pin number
1
VBUS (power)
2
DM
3
DP
Audio jack CN3
A 3.5 mm stereo audio jack, CN3, connected to audio DAC is available.
Description
Pin number
5,6
Description
Pin number
Doc ID 18141 Rev 1
UM1018
Description
4
GND
Shield
Description
4
GND
5
Shield
6
Shield
