Specifications

1.1 Feature List

Table 1
Form Factor
Processor
Memory
Chipset
Audio
Ethernet
Graphics Options
Super I/O
Peripheral Interfaces
BIOS
Power Management
Note
Some of the features mentioned in the above Feature Summary are optional. Check the
article number of your module and compare it to the option information list on page 7 of
this user's guide to determine what options are available on your particular module.
Copyright © 2006 congatec AG
Feature Summary
ETX ® standard (Rev. 2.7) with XTX
AMD Geode™ LX800 500MHz with 128 kByte cache
SO-DIMM DDR (up to PC2700) maximum 1-GByte
AMD Geode™ CS5536 companion device
Realtek ALC203 AC'97 Rev. 2.2 compatible.
Realtek RTL8100C
Similar to GX graphics core but with strong improvements. Unified Memory Architecture
(UMA) with a maximum of 16MB hardware frame buffer compression. 2-254MB graphics
memory space.
CRT Interface
•
350 MHz RAMDAC
Resolutions up to 1920x1440 @ 85Hz
Flat panel Interface
•
External LVDS Transmitter
Supports 1x18Bit TFT configurations
Automatic Panel Detection via EPI
(Embedded Panel Interface based on
VESA EDID™ 1.3)
Resolutions 640x480 up to 1024x768
(XGA)
Optional direct TTL interface, max.
resolution 1024x768 1x18Bit
Winbond 83627HG
2x Serial ATA
®
•
PCI Bus Rev. 2.2
•
LPC Bus (no ISA Bus)
•
2x EIDE (UDMA-66/100)
•
4x USB 2.0 (EHCI)
•
AC'97 Digital Audio Interface
•
Based on Insyde XpressROM 1MByte Flash BIOS with congatec Embedded BIOS
features
ACPI 2.0 compliant with battery support. Also supports Suspend to RAM (S3).
TM extension
•
•
•
•
•
•
•
•
X800m12
Motion Video Support
Hardware Up- and Downscaling
High definition digital video support
Alpha blending and color keying
TV Out (optional)
External TV encoder
Supports component + S-Video
Supports HDTV (420p, 720p & 1080i)
I C Bus, Fast Mode (400 kHz)
2
Floppy (shared with LPT)
LPT (EEP/ECP, shared with floppy)
2 x COM Ports, TTL Level
1 x IrDA Port
PS/2 Keyboard, Mouse
