Congatec XTX conga-XLX User Manual page 43

Table 22
Pin Signal Name
1 GND
3 R
5 HSY
7 VSY
9 DETECT# (*)
11 LCDDO[16] (*)
13 LCDDO[17] (*)
15 GND
17 LCDDO[13] (*)
19 LCDDO[12] (*)
21 GND
23 LCDDO[8] (*)
25 LCDDO[9] (*)
27 GND
29 LCDDO[4]
31 LCDDO[5]
33 GND
35 LCDDO[1]
37 LCDDO[0]
39 VCC
41 FPDDC_DAT
43 FPDDC_CLK
45 BIASON (*)
47 COMP
49 SYNC
TX1= Channel 1 transmit
TX2= Channel 2 transmit
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-XLX.
Table 23
Signal Description of TTL Flat Panel Signals
HSYNC Horizontal synchronization pulse
VSYNC Vertical synchronization pulse
BIASON N.A.
DIGON Controls display Power ON
BLON# Controls display Backlight ON
R[0..5], B[0..5], RGB Signals
G[0..5]
SHFCLK Panel data clock
Copyright © 2006 congatec AG
LVDS Interface Pinout
Signal Mapping
TX2OUTCLK-
TX2OUTCLK+
TX2OUT1+
TX2OUT1-
TX1OUT3-
TX1OUT3+
TX1OUT2-
TX1OUT2+
TX1OUT0+
TX1OUT0-
TTL Flat Panel Signals
Pin Signal Name
2 GND
4 B
6 G
8 DDCK
10 DDDA
12 LCDDO[18] (*)
14 LCDDO[19] (*)
16 GND
18 LCDDO[15] (*)
20 LCDDO[14] (*)
22 GND
24 LCDDO[11] (*)
26 LCDDO[10] (*)
28 GND
30 LCDDO[7]
32 LCDDO[6]
34 GND
36 LCDDO[3]
38 LCDDO[2]
40 VCC
42 LTGIO0
44 BLON#
46 DIGON
48 Y
50 C
I/O PU/PD
O 3.3V
O 3.3V
O 5V PD 10k
O 5V
O 3.3V
O 3.3V
X800m12
Signal Mapping
TX2OUT3-
TX2OUT3+
TX2OUT2+
TX2OUT2-
TX2OUT0+
TX2OUT0-
TX1OUTCLK+
TX1OUTCLK-
TX1OUT1+
TX1OUT1-
Comment
Also referred to as LP (Line
Pulse)
Also referred to as FLM (First
Line Marker)
43/72
