8.5.8

Watchdog Configuration Submenu

Feature
Watchdog Parameter
Configuration
POST Watchdog
Runtime Watchdog
Delay
Event 1
Event 2
Event 3
Timeout 1
Timeout 2
Timeout 3
Copyright © 2006 congatec AG
Options
No Option
Disabled
30sec
1min
2min
5min
10min
30min
Disabled
One time trigger
Single Event
Repeated Event
see Post Watchdog
NMI
ACPI Event
Reset
Power Button
Disabled
NMI
ACPI Event
Reset
Power Button
Disabled
NMI
ACPI Event
Reset
Power Button
0.5sec
1sec
2sec
5sec
10sec
30sec
1min
2min
see above
see above
Description
Selects the timeout value for the POST watchdog.
The watchdog is only active during the power-on-self-test of the
system and provides a facility to prevent errors during bootup by
performing a reset.
Selects the operating mode of the runtime watchdog.
This watchdog will be initialized just before the operating system
starts booting.
If set to 'One time trigger' the watchdog will be disabled after the first
trigger.
If set to 'Single event', every stage will be executed only once, then
the watchdog will be disabled.
If set to 'Repeated event' the last stage will be executed repeatedly
until a reset occurs.
Select the delay time before the runtime watchdog becomes active.
This ensures that an operating system has enough time to load.
Selects the type of event that will be generated when timeout 1 is
reached.
Selects the type of event that will be generated when timeout 2 is
reached.
Selects the type of event that will be generated when timeout 3 is
reached.
Selects the timeout value for the first stage watchdog event.
Selects the timeout value for the second stage watchdog event.
Selects the timeout value for the third stage watchdog event.
