was set to 800x600 32bit High Color. The "Performance Control" was set to the BIOS
default value "Manual Settings", which is 500MHz CPU clock speed. The conga-XLX
was tested while using a swissbit
different sizes of RAM will cause slight variances in the measured results. Power
consumption values were recorded during the following stages:
Windows XP Professional SP2
Desktop Idle
•
100% CPU workload (see note below)
•
Windows Standby (see note below)
•
Suspend to RAM (requires setup node "Suspend Mode Control" in BIOS to be
•
configured to S3-State (suspend to RAM)).
Note
A software tool was used to stress the CPU to 100% workload.
ACPI OS Standby = S1 = POS = CPU is in sleep mode (internal clocks stopped, no
snoops)
1.5.1

conga-XLX 500MHz with 128 kByte cache

With 512MB memory installed
conga-XLX Art. No. 057824
LVDS variant
Memory Size
Operating System
Power State
Power consumption (measured
in Amperes/Watts)
1.5.2 conga-XLX 500MHz with 128 kByte cache
With 512MB memory installed
conga-XLX Art. No. 084267
TTL variant
Memory Size
Operating System
Power State
Power consumption (measured
in Amperes/Watts)
Copyright © 2006 congatec AG
® DDR PC2700 512MB memory module. Using
AMD Geode™ LX800 500MHz with 128 kByte cache
Layout Rev. X800LA0 /BIOS Rev. X800R114
512MB
Windows XP Professional SP2
Desktop Idle 100% workload Standby
1.2 A/6 W 1.5 A/7.5 W
AMD Geode™ LX800 500MHz with 128 kByte cache
Layout Rev. X800LA0 /BIOS Rev. X800R114
512MB
Windows XP Professional SP2
Desktop Idle 100% workload Standby
1.3 A/6.5 W 1.7 A/8.5 W
X800m12
Suspend to Ram (S3)
1.0 A/5 W 0.2 A/1 W
Suspend to Ram (S3)
1.1 A/5.5 W 0.2 A/1 W
