8.5.5

I/O Interface Configuration Submenu

Feature
I/O Interface
Configuration Submenu
Floppy Support
Keyboard Support
Serial Port 1
Serial Port 2
Serial Port 2 Mode
IR Duplex Mode
IR I/O Pin Select
Parallel Port Address
Parallel Port Mode
Parallel Port IRQ
Parallel Port DMA
External Super I/O
Configuration Menu
Copyright © 2006 congatec AG
Options
No Option
Enabled
Disabled
Enabled
Disabled
Disabled
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Normal
IrDA
ASK IR
Full Duplex
Half Duplex
SINB/SOUTB
IRRX/RTX
Disabled
378
278
3BC
Compatible
Bi-directional
EPP 1.7
EPP 1.9
ECP
None
IRQ5
IRQ7
IRQ9
IRQ10
IRQ11
None
DMA1
DMA3
Submenu
Description
Enables/Disables the onboard Super I/O floppy device.
Note: The floppy drive and the parallel port share the same pins
on the conga-XLX. Only one device can be driven at any given
time. If the floppy drive is to be used, the parallel port must be
disabled.
Enables/Disables keyboard support.
Note: If the keyboard support is disabled it is not possible to
enter system setup. If the keyboard is not used by the
application then the POST process can be sped up by disabling
keyboard support.
Specifies the I/O base address and IRQ of serial port 1.
Specifies the I/O base address and IRQ of serial port 2.
Specifies the mode for serial port 2.
Select IRDA full or half duplex function.
Select the receive and transmit pins for IRDA mode.
Specifies the I/O base address used by the parallel port.
Note: The parallel port and the floppy drive share the same pins
on the conga-XLX. Only one device can be driven at any given
time. If the parallel port is to be used, the floppy drive must be
disabled.
Specifies the parallel port mode.
Specifies the interrupt for the parallel port.
Specifies the DMA channel for the parallel port in ECP mode.
Submenu for external Super I/O configuration.
Note: This submenu is only selectable if a external Winbond
W83627HG Super I/O is present.
