8.6 Performance Control

Select the 'Performance Control' submenu from the main setup menu and press enter

or press the related letter in front of the menu to enter the 'Performance Control' Setup

screen. The menu is used for setting system clocks.

Feature

System Clock Mode

CPU Clock Speed

Note

congatec strongly recommends that when using the 'Manual Settings' option the 'CPU

Clock Speed' should be set to the default value, which is 500MHz. If an alternative

setting for the 'CPU Clock Speed' must be used then it's recommended that this setting

be extensively evaluated in conjunction with the complete system.

Options

Hardware Strapping

Manual Settings

333 Mhz

366 Mhz

400 Mhz

433 Mhz

466 Mhz

500 MHz

Description

Selects if system clocks should be determined by manual settings

or by hardware bootup straps.

Set the CPU clock speed.

Hardware Strapping = CPU Clock Speed: 400MHz

X800m12

67/72
