Table 28
Pin Signal
51 LPT (*)
53 VCC
55 STB#
57 RESERVED
59 IRRX
61 IRTX
63 RXD2
65 GND
67 RTS2#
69 DTR2#
71 DCD2#
73 DSR2#
75 CTS2#
77 TXD2
79 RI2#
81 VCC
83 RXD1
85 RTS1#
87 DTR1#
89 DCD1#
91 DSR1#
93 CTS1#
95 TXD1
97 RI1#
99 GND
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-XLX.
Copyright © 2006 congatec AG
LPT Support Mode Pinout
Parallel Port Mode Pinout
Pin Signal
52 RESERVED
54 GND
56 AFD#
58 PD7
60 ERR#
62 PD6
64 INIT#
66 GND
68 PD5
70 SLIN#
72 PD4
74 PD3
76 PD2
78 PD1
80 PD0
82 VCC
84 ACK#
86 BUSY
88 PE
90 SLCT
92 MSCLK
94 MSDAT
96 KBCLK
98 KBDAT
100 GND
