1.6 Supply Voltage Battery Power

2.4-3.6V
•
Typical 3.0V
•
1.6.1

CMOS Battery Power Consumption

RTC @ 20ºC
Integrated in the
AMD Geode™ CS5536
companion device
The CMOS battery power consumption value listed above should not be used to
calculate CMOS battery lifetime. You should measure the CMOS battery power
consumption in your customer specific application in worst case conditions, for example
during high temperature and high battery voltage. The self-discharge of the battery must
also be considered when determining CMOS battery lifetime. For more information
about calculating
AN9_RTC_Battery_Lifetime.pdf, which can be found on the congatec AG website at
www.congatec.com.

1.7 Environmental Specifications

Temperature
Humidity
Caution
The above operating temperatures must be strictly adhered to at all times. When using
a heatspreader the maximum operating temperature refers to any measurable spot on
the heatspreader's surface.
congatec AG strongly recommends that you use the appropriate congatec module
heatspreader as a thermal interface between the module and your application specific
cooling solution.
If for some reason it is not possible to use the appropriate congatec module
heatspreader, then it is the responsibility of the operator to ensure that all components
found on the module operate within the component manufacturer's specified
temperature range.
For more information about operating a congatec module without heatspreader contact
congatec technical support.
Humidity specifications are for non-condensing conditions.
Copyright © 2006 congatec AG
Voltage
3V DC
CMOS battery
Operation: 0° to 60°C
Operation: 10% to 90%
X800m12
Current
1.53 µA
lifetime refer
Storage: -20° to +80°C
Storage: 5% to 95%
to application
15/72
