Specifications

2.1

Feature List

Form Factor SMARC
SoC NXP
Memory
1, 2 or 4 GB onboard LPDDR4 memory @ 1200 MHz
Storage
SPI NOR flash memory with up to 256 Mbit (64 Mbit assembled by default)
eMMC™ 5.1 HS400 with up to 128 GB (16 GB assembled by default)
Audio Up to 2x I
Ethernet
Up to 2x GbE with support for IEEE 1588 (i.MX 8DualX SoC only supports 10/100 Mbps on GBE1)
Display
Support for up to two independent displays:
2x Single channel LVDS/DSI or 1x Dual channel LVDS/DSI (default)
Interfaces
or 1x Single channel LVDS/DSI and 1x HDMI (assembly option for commercial variants only; default on PN: 051105)
Peripheral
1x MIPI CSI-2 with four lanes
1x SD/SDIO Card Interface
Interfaces
2x SPI
I²C
Up to 4x Serial Ports (SER3 instead of CAN1 via assembly option)
2x CAN with support for CAN FD (FlexCAN)
1x USB 2.0 OTG
Up to 2x USB 2.0 (Wi-Fi/BT instead of USB4 via assembly option)
Up to 2x USB 3.0/2.0 (i.MX 8DualX SoC only supports USB 2.0)
Features
Watchdog timer
Bootloader
U-Boot
Virtualization
Multiple domains with hardware virtualization
Multiple Operating Systems
Security
High Assurance Boot (HAB)
TrustZone
Copyright © 2020 congatec AG
form factor specification, revision 2.0 (82 mm x 50 mm)
®
i.MX 8QuadXPlus, 8DualXPlus, or 8DualX
®
S (only 1x I S with HDMI)
2 2
®
1x PCI Express x1 Gen3
12x GPIOs
1x Onboard JTAG Debug Connector (assembly option)
1x Onboard A35 Console and SCU Debug Connector
1x Onboard Wi-Fi/BT M.2 1216 Module (assembly option; default on PN: 051104)
NOTE:
Requires RS-232 adapter cable PN: 48000023 (See Table 3).
1
Onboard Discrete Real-Time Clock (RTC)
System MMU
Resource partitioning and split GPU
Cryptographic Acceleration and Assurance Module (CAAM)
SX8Xm01
1
