Congatec XTX conga-XLX User Manual page 33

Table 5
Signal Description of USB Signals
USB0 USB Port 0, data + or D+
USB0# USB Port 0, data - or D-
USB1 USB Port 1, data + or D+
USB1# USB Port 1, data - or D-
USB2 USB Port 2, data + or D+
USB2# USB Port 2, data - or D-
USB3 USB Port 3, data + or D+
USB3# USB Port 3, data - or D-
Table 6
Signal Description of Audio Signals
SNDL Line-Level stereo output left
SNDR Line-Level stereo output right
AUXAL Auxiliary input A left
AUXAR Auxiliary input A right
MIC Microphone input
ASGND Analog ground of sound controller
ASVCC Analog supply of sound controller
Copyright © 2006 congatec AG
USB Signal Descriptions
Audio Signal Descriptions
I/O PU/PD
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O PU/PD
O
O
I 22k PD
I 22k PD
I 2k2 PU to Audio
Vref (2,5V)
P
P
X800m12
Comment
USB 2.0 compliant and backwards
compatible to USB 1.1
USB 2.0 compliant and backwards
compatible to USB 1.1
USB 2.0 compliant and backwards
compatible to USB 1.1
USB 2.0 compliant and backwards
compatible to USB 1.1
USB 2.0 compliant and backwards
compatible to USB 1.1
USB 2.0 compliant and backwards
compatible to USB 1.1
USB 2.0 compliant and backwards
compatible to USB 1.1
USB 2.0 compliant and backwards
compatible to USB 1.1
Comment
Analog output (1 Vrms)
Analog output (1 Vrms)
Analog input (1 Vrms)
Analog input (1 Vrms)
Analog input (1 Vrms)
5V power output (Can be used as
an analog supply for analog
amplifier maximum 30mA)
33/72
