8

BIOS Setup Description

The following section describes the BIOS setup program. The BIOS setup program can
be used to view and change the BIOS settings for the module. Only experienced users
should change the default BIOS settings.

8.1 Starting the BIOS setup program

The BIOS setup program is accessed by pressing the <DEL> key during POST.
8.1.1

Manufacturer Default Settings

Pressing the <End> key repeatedly immediately after power is initiated will result in the
manufacturer default settings being loaded for that particular boot sequence and only
that boot sequence. This is helpful when a previous BIOS setting is no longer desired.

8.2 Setup Menu and Navigation

The congatec BIOS setup screen is composed of main frames, with submenu
selections. The main frame displays all the options that can be configured in the
selected menu. Grayed-out options cannot be configured, only the highlighted options
can be configured. An option setting can be chosen by pressing the ↑↓Up/Down keys.
The actual available setting is displayed on the right side of the option. The bottom line
of the frame displays a short help text related to the option. These text messages
explain the options and the possible impacts when changing a setting of the selected
option in the frame. The setup program uses a key-based navigation system. Most of
the keys can be used at any time while in setup. The table below explains the supported
keys:
Note
Entries in the option column displayed in bold print indicate BIOS default values.
Key
← → Left/Right
↑ ↓ Up/Down
+ - Plus/Minus
Tab
F1
<L>
<S>
<X>
<Q>
ENTER
ESC
Copyright © 2006 congatec AG
Description
Select a setup item or sub menu.
Select a setup item or sub menu.
Change the field value of a particular setup item.
Select next item.
Display General Help screen.
Load optimal default settings. (only valid in main menu)
Save changes without exit setup. (only valid in main menu)
Save changes and exit setup. (only valid in main menu)
Discard changes and exit setup. (only valid in main menu)
Set an option of a particular setup item or enter sub menu.
Confirm changes of the actual menu/submenu and go to next menu.
