Feature
LPC DRQ Routing
Network Controller
System Beeper
8.5.6

External Super I/O Configuration Submenu

Feature
External Super I/O
Configuration Submenu
Floppy Support
Serial Port 1
Serial Port 2
Parallel Port
Parallel Port Mode
Parallel Port IRQ
Parallel Port DMA
Note
This submenu is only available if an external Winbond W83627HG Super I/O controller
is present in the system. The configuration base I/O address of the Super I/O has to be
0x4E and 0x4F.
Copyright © 2006 congatec AG
Options
Onboard Super I/O
External LPC Device
Disabled
Enabled
Disabled
Enabled
Options
No Option
Enabled
Disabled
Disabled
3E8/IRQ11
3E8/IRQ10
2E8/IRQ11
2E8/IRQ10
Disabled
3E8/IRQ11
3E8/IRQ10
2E8/IRQ11
2E8/IRQ10
Disabled
378
278
3BC
SPP
EPP 1.7
EPP 1.9
ECP
Disabled
IRQ5
IRQ7
Disabled
DMA1
DMA3
Description
Select if LPC DRQ line should be routed to the onboard Super
I/O or the external LPC Device. If the onboard floppy drive or the
ECP parallel port is enabled, the LPC DRQ has to be routed to
the onboard Super I/O controller.
Enables/Disables the onboard PCI network controller.
Enables/Disables the external system beeper.
Description
Enables/Disables floppy device of the external Super I/O controller.
Note: The external Floppy only can be used, if the onboard Floppy
is disabled. Otherwise the there is a resource conflict.
Specifies the I/O base address and IRQ of the serial port 1 of the
external Super I/O controller.
Specifies the I/O base address and IRQ of the serial port 2 of the
external Super I/O controller.
Specifies the I/O base address used by the parallel port of the
external Super I/O controller.
Specifies the parallel port mode of the external Super I/O controller.
Specifies the interrupt for the parallel port of the external Super I/O
controller.
Specifies the DMA channel for parallel port in ECP mode.
