6.2 Connector X1 Pinout

Table 7
Pin Signal
1 GND
3 PCICLK3
5 GND
7 PCICLK1
9 REQ3#
11 GNT2#
13 REQ2#
15 REQ1#
17 GNT0#
19 VCC
21 SERIRQ
23 AD0
25 AD1
27 AD4
29 AD6
31 CBE0#
33 AD8
35 GND
37 AD10
39 AD11
41 AD12
43 AD13
45 AD14
47 AD15
49 CBE1#
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-XLX.
Copyright © 2006 congatec AG
X1 Connector Pinout
Pin Signal
2 GND
4 PCICLK4
6 GND
8 PCICLK2
10 GNT3#
12 3V
14 GNT1#
16 3V
18 RESERVED
20 VCC
22 REQ0#
24 3V
26 AD2
28 AD3
30 AD5
32 AD7
34 AD9
36 GND
38 AUXAL
40 MIC
42 AUXAR
44 ASVCC
46 SNDL
48 ASGND
50 SNDR
Pin Signal
51 VCC
53 PAR
55 GPERR# (*)
57 PME#
59 LOCK# (*)
61 TRDY#
63 IRDY#
65 FRAME#
67 GND
69 AD16
71 AD17
73 AD19
75 AD20
77 AD22
79 AD23
81 AD24
83 VCC
85 AD25
87 AD28
89 AD27
91 AD30
93 PCIRST#
95 INTC#
97 INTA#
99 GND
X800m12
Pin Signal
52 VCC
54 SERR# (*)
56 Reserved
58 USB2#
60 DEVSEL#
62 USB3#
64 STOP#
66 USB2
68 GND
70 CBE2#
72 USB3
74 AD18
76 USB0#
78 AD21
80 USB1#
82 CBE3#
84 VCC
86 AD26
88 USB0
90 AD29
92 USB1
94 AD31
96 INTD#
98 INTB#
100 GND
