6.5 X3 Connector Signal Descriptions

Table 16
Signal Description
VCC Power Supply +5VDC, ±5%
GND Power Ground
N.C. Not connected
LTGIO0 General Purpose I O
Table 17
Signal Description of CRT signals
HSY Horizontal Synchronization Pulse
VSY Vertical Synchronization Pulse
R Red channel RGB Analog Video Output
G Green channel RGB Analog Video Output
B Blue channel RGB Analog Video Output
DDCK Display Data Channel Clock
DDDA Display Data Channel Data
Table 18
Signal Description of TV signals (optional)
SYNC Composite sync
Y Luminance for S-Video or Red for SCART
C Chrominance for S-Video or Green for SCART
Comp Composite Video or Blue for SCART
Table 19
Signal Description of keyboard
and infrared signals
KBDAT Keyboard Data
KBCLK Keyboard Clock
MSDAT Mouse Data
MSCLK Mouse Clock
IRTX Infrared Transmit
IRRX Infrared Receive
Copyright © 2006 congatec AG
Signal Descriptions
CRT Signal Descriptions
TV Signal Descriptions
Keyboard and Infrared Signal Descriptions
I/O
I/O 5V
O 5V
I/O 5V
O 5V
O 5V
I 5V
I/O PU/PD
P
P
N.A.
N.A.
I/O PU/PD
O 3.3V
O 3.3V
O
O
O
I/O PU 2k2 5V
I/O PU 2k2 5V
I/O PU/PD
O
O
O
O
PU/PD
PU 4k7 5V
PU 4k7 5V
PU 4k7 5V
PU 4k7 5V
X800m12
Comment
External supply
External supply
Do not connect
Not supported
Comment
5V tolerant
5V tolerant
Analog output
Analog output
Analog output
Comment
Analog output
Analog output
Analog output
Analog output
Comment
