8.3 Main Menu

When you first enter the BIOS setup, you will enter the 'Main Menu' screen. You can
always return to the 'Main Menu' screen by using the ESC key.
The 'Main Menu' screen allows you to configure the system date and time, displays the
available submenus and defines the exit procedure. The headline in the 'Main Menu'
screen shows the recent BIOS version and build date.
Feature / Submenu
A. Time
B. Date
C: Board Information
D. Device Configuration
E. Power Management
F. Performance Control
G. Boot Order
L. Load Defaults
S. Save Values Without Exit
Q. Exit Without Save
X. Save values and Exit

8.4 Board Information

The 'Board Information' screen shows the product revision, board serial number, board
controller firmware revision and board statistics.
Feature
Product Revision
Serial Number
BC Firmware Rev.
Boot Counter
Running Time
OEM BIOS Version
Copyright © 2006 congatec AG
Options
Hour:Minute:Second
Day of week,
month/day/year
Options
no option
no option
no option
no option
no option
no option
Description
Specifies the current time.
Note: The time is in 24-hour format.
Specifies the current date.
Note: The date is in month-day-year format.
Displays the board information submenu.
Displays the device configuration submenu.
Displays the power management submenu.
Displays the performance control submenu.
Displays the boot order submenu.
Load the system CMOS defaults of all the setup options.
Save changes made in the BIOS setup without exiting setup.
Exit setup without saving any changes made in the BIOS setup.
Exit setup and reboot so the new system configuration
parameters can take effect.
Description
Displays the hardware revision of the board.
Displays the serial number of the board.
Displays the revision of the congatec board controller.
Displays the number of boot-ups (max. 16777215).
Displays the time the board is running [in h] (max. 65535).
Displays the OEM BIOS version string that is generated during OEM
BIOS modification.
