Specifications

2.1

Feature List

Table 5 Feature Summary
Form Factor
Processor
Memory
Audio
Ethernet
Graphics Options
Peripheral
Interfaces
Onboard Interfaces
and Devices
Bootloader
Power Mgmt.
Note
Some of the features mentioned in the above feature summary are optional. Check the article number of your module and compare it to the
conga-QMX6 options information list on page 12 of this user's guide to determine what options are available on your particular module.
Copyright © 2013 congatec AG
Based on Qseven ® form factor specification revision 2.0
NXP i.MX6 Cortex A9
®
Up to 4 GB onboard DDR3L memory
I2S format supported
Gigabit Ethernet (Qualcomm Atheros PHY) on conga-QMX6 rev B.x and later. Earlier conga-QMX6 variants are equipped with Micrel KSZ9031 PHY.
Integrated video graphic subsystem consisting of Video Processing Unit (VPU), Graphic Processing Unit (3D GPU, 2D GPU, Open VG), Image
Processing Unit, Display interface bridges (LVDS, HDMI, MIPI/DSI).
1x HDMI 1.4.
2x LVDS channels driven by the LVDS display bridge. Support:
-
Single channel LVDS interface : 1 x 18 bpp or 1 x 24 bpp (up to 85 MHz per
interface e.g 1366x768 @ 60Hz + 35% blanking)
-
Dual channel LVDS interface: 2 x 18 bpp OR 2 x 24 bpp (up to 170 MHz pixel
clock e.g 1600x1200 @ 60 Hz + 35% blanking).
NOTE:
Supports three independent displays (must be 2x single channel LVDS and 1x HDMI)
1x Serial ATA Gen 2 (3GB/s)
®
1x SDIO
x1 PCI Express Lane Gen 2.0 offering up to 5 GB/s
5x USB 2.0 ports (4x USB 2.0 hosts and 1x USB 2.0 OTG)
I2S Bus
SPI
CAN
Android Buttons
JTAG
RS-232 Debug Port
SPI Flash (contains the bootloader)
Pre-installed open-source bootloader (U-boot)
Yes.
Video Decode Acceleration:
-
MPEG2 MP, HP
-
MPEG4 SP
-
H.264
-
VC-1
-
DivX
8x GPIOs
3x I²C fast mode, multi-master (two shared I²C buses and one
unshared bus)
1x UART (fully featured UART with control signals, supported
on the MXM connector)
2x RS-232 interfaces supported onboard the conga-QMX6 via
RS232 transceiver.
DDR3 SDRAM memory (up to 2 GB)
Micro-SD Socket
eMMC module (up to 8GB onboard)
