Signal Descriptions and Pinout Tables

The following section describes the signals found on the four X connectors located on
the bottom of the module. X1, X3, and X4 connectors are ETX
while the X2 connector complies with the XTX
This table describes the terminology used in this section for the Signal Description
tables. The PU/PD column indicates if an XTX
been used. If the field entry area in this column for the signal is empty, then no pull-up
or pull-down resistor has been implemented. The "#" symbol at the end of the signal
name indicates that the active or asserted state occurs when the signal is at a low
voltage level. When "#" is not present, the signal is asserted when at a high voltage
level.
Table 2
Term Description
PU XTX
PD XTX
I/O 3.3V Bi-directional signal 3.3V tolerant
I/O 5V Bi-directional signal 5V tolerant
I 3.3V Input 3.3V tolerant
I 5V Input 5V tolerant
I/O 3.3VSB Input 3.3V tolerant active in standby state
O 3.3V Output 3.3V signal level
O 5V Output 5V signal level
P Power Input/Output
DDC Display Data Channel
PCIE In compliance with PCI Express Base Specification, Revision 1.0a
SATA In compliance with Serial ATA specification, Revision 1.0a
LVDS Low Voltage Differential Signal-350mV nominal; 450mV maximum differential signal
TPM Trusted Platform Module

6.1 X1 Connector Signal Descriptions

Table 3
Signal Description
VCC Power Supply +5VDC ±5%
GND Power Ground
3V Power Supply +3.3VDC
N.C. Not Connected
SERIRQ Serial Interrupt request
Copyright © 2006 congatec AG
Signal Tables Terminology Descriptions
® Internally implemented Pull up resistor
Internally implemented Pull down resistor
®
Signal Descriptions
TM extension specification.
® internal pull-up or pull-down resistor has
I/O PU/PD
P
P
P
N.A.
I
X800m12
® standard compliant
Comment
External supply
External supply
See section 4.1.4
Do not connect
Used in conjunction with LPC bus
