Revision History
Revision Date (dd.mm.yy)
1.0 20.02.06
1.1 20.09.06
1.2 06.08.07
Copyright © 2006 congatec AG
Author Changes
GDA Initial release
GDA Updated Power Consumption Tables in section 1.5. Added CMOS
backup battery information. Updated heatspreader drawing. Added
section 5.3.1 Simplified Overview of BIOS Setup Data Backup. Added
Note and Caution statement found below PCI Signal Description Table 4
in section 6.1. Updated BIOS Setup Description section section 8.
GDA Added Electrostatic Sensitive Device information. Changed all audio
codec references to ALC203. ALC658 is no longer used on conga-XLX.
Added section 1.4 Electrical Characteristics and 1.4.1 Supply Voltage
Ripple. Added description for PP_TPM pin 60 on X2 connector. Added
information about center mounting hole to 'Caution' statement in section
3 Heatspreader. Added information to 'Caution' statement in section
4.1.4 Onboard Generated Supply Voltage. Added note about floppy
cable to section 4.3.6 Parallel Port/Floppy Interface. Added section 5.5
'congatec Battery Management Interface'. Added LVDS signal mapping
to table 17 LVDS Interface Pinout. Updated section 7 System Resources
and section 8 BIOS Setup Description.
