Congatec XTX conga-XLX User Manual page 44

Table 24
Table 25
Signal Description of FDC signals (shared with LPT)
FLPY# Floppy Interface configuration input
RES N.C.
DENSEL Density select: low = 250/300Kb/s high = 500/1000Kb/s
INDEX# Index signal
TRK0# Track signal
WP# Write protect signal
RDATA# Raw data read
DSKCHG# Disk change
HDSEL# Head select
DIR# Direction
STEP# Motor step
DRV Drive select
MOT# Motor select
WDATA# Raw write data
WGATE# Write enable
Copyright © 2006 congatec AG
TTL Flat Panel Interface Pinout
TTL Interface Pinout
Pin Signal
1 GND
3 R
5 HSY
7 VSY
9 DETECT# (*)
11 B4
13 B5
15 GND
17 B1
19 B0
21 GND
23 G2
25 G3
27 GND
29 R4
31 R5
33 GND
35 R1
37 R0
39 VCC
41 FPDDC_DAT
43 FPDDC_CLK
45 HSYNC
47 COMP
49 SYNC
FDC Signal Descriptions
Pin Signal
2 GND
4 B
6 G
8 DDCK
10 DDDA
12 SHFCLK
14 EN
16 GND
18 B3
20 B2
22 GND
24 G5
26 G4
28 GND
30 G1
32 G0
34 GND
36 R3
38 R2
40 VCC
42 VSYNC
44 BLON#
46 DIGON
48 Y
50 C
I/O
N.A.
N.A.
O 5V
I 5V
I 5V
I 5V
I 5V
I 5V
O 5V
O 5V
O 5V
O 5V
O 5V
O 5V
O 5V
X800m12
PU/PD Comment
Not supported, see
section 4.3.5 for more
information.
Not available
44/72
