Congatec XTX conga-XLX User Manual page 40

Pin XTX TM Signal
67 GND
69 PCIE0_RX- (*)
71 PCIE0_RX+ (*)
73 GND
75 PCIE0_TX- (*)
77 PCIE0_TX+ (*)
79 CODECSET
81 AC_RST#
83 VCC
85 AC_SYNC
87 AC_SDIN1 (*)
89 AC_BIT_CLK
91 LPC_AD0
93 LPC_AD1
95 LPC_AD2
97 LPC_AD3
99 GND
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-XLX.
Copyright © 2006 congatec AG
ETX ® Reference
GND
SA13
SA14
SA15
SA16
SA18
SA19
IOCHRDY
VCC
SD0
SD2
SD3
DREQ2
SD5
SD6
IOCHK#
GND
X800m12
Pin XTX TM Signal
68 GND
70 RESERVED
72 RESERVED
74 VCC
76 RESERVED
78 RESERVED
80 VCC
82 AC_SDOUT
84 VCC
86 AC_SDIN0
88 AC_SDIN2
90 FAN_TACHOIN
92 FAN_PWMOUT
94 LPC_FRAME#
96 LPC_DRQ0#
98 LPC_DRQ1#
100 GND
ETX ® Reference
GND
DREQ3
DACK3#
IOR#
IOW#
SA17
SMEMR#
AEN
VCC
SMEMW#
SD1
NOWS#
SD4
IRQ9
SD7
RSTDRV
GND
