SD
Use the following steps to boot from an SD card.
1. Store a valid Zynq UltraScale+ RFSoC boot image file onto an SD card (plugged into SD
socket J23) connected to the MIO[39:51] SD interface.
2. Set the boot mode pins SW3 [4:1] as indicated in the table above for SD.
3. Either power-cycle or press the power-on reset (POR) pushbutton. SW2 is callout 11 in
Figure
3.
See the Zynq UltraScale+ Device Technical Reference Manual (UG1085) for more information about
Zynq UltraScale+ RFSoC configuration options.
UG1390 (v1.1) July 10, 2020
ZCU216 Board User Guide
Chapter 2: Board Setup and Configuration
Send Feedback
www.xilinx.com
21
